Ebara 2CDX 70/12 Twin Impeller Centrifugal Pump – 161112-0004 – 0.88 kW – 400V – 3 Phase
by Ebara
SKU 161112-0004
Original price
$1,212.75
-
Original price
$1,212.75
Original price
$1,212.75
$1,212.75
-
$1,212.75
Current price
$1,212.75
📢 For orders over $100, FREE Shipping Australia-wide
The Ebara 2CDX 70/12 is a three-phase, twin impeller centrifugal pump designed for domestic water supply and pressure boosting applications requiring higher heads. Constructed with a robust AISI 304 stainless steel pump casing, twin impellers, and diffuser, this unit features a carbon/ceramic/NBR mechanical seal for reliable performance. The pump has a maximum liquid temperature of 60°C and a maximum working pressure of 8 bar. Three phase motors require external overload protection to be provided by the installer.
Suitable Applications
- Domestic water supply and pressure boosting
- Small-scale garden irrigation
- Water transfer from tanks and wells
- Heating, ventilation, air-conditioning and cooling
- Handling of clean water in general
- Washing plants and membrane filtration
- Cooling towers
- Sprinkler and flow irrigation
- Beverage processing and pharmaceutical services
Key Specifications
| Product Name | 2CDX 70/12 | Product Number | 161112-0004 |
| Pump Type | Twin Impeller Centrifugal Pump (Closed impellers) |
| Discharge / Suction Size | 25 mm / 32 mm (G1" discharge, G1¼" suction) |
| Motor Power (P2) | 0.88 kW (1.2 HP) | Voltage | 400V |
| Phase | Three phase (3 ph) |
| Maximum Flow Rate | Up to 12.6 m³/h |
| Maximum Head | Up to 75 m |
| Maximum Liquid Temperature | 60°C (110°C with optional high temperature seal) | Minimum Liquid Temperature | -5°C |
| Maximum Working Pressure | 8 bar |
| Connections | Suction: G1¼" (UNI ISO 228); Discharge: G1" (UNI ISO 228) |
| Pump Casing Material | AISI 304 Stainless Steel |
| Impeller Material | AISI 304 Stainless Steel (Twin closed type) |
| Diffuser Material | AISI 304 Stainless Steel |
| Shaft Material (wetted parts) | AISI 304 Stainless Steel |
Performance Data
| Flow Rate (L/min) | 0 | 20 | 40 | 60 | 80 |
| Flow Rate (m³/h) | 0 | 1.2 | 2.4 | 3.6 | 4.8 |
| Total Head (m) | 44.5 | 40.3 | 35.5 | 30.0 | — |
