Transducers Built for Australian Pump, Bore and Pressure Systems

A transducer is the part of your system that tells the truth about what is happening inside the pipe. Pumptastic stocks a working range of industrial pressure and submersible level transducers, held in stock at our Western Australian workshop and shipped Australia-wide, free on orders over $100. Every transducer here is specified at 0.5% full scale accuracy, machined in SS316L stainless, and sealed to IP66. Those are numbers off a datasheet, not marketing. If you need a transducer today for a pressure pump, a bore, a tank or a control panel, you can see the price, see the stock, and order it now.

What a Transducer Actually Does

A transducer turns a physical thing, pressure or liquid depth, into an electrical signal a machine can read. Our transducer range outputs 4-20mA over two wires. That signal goes straight into a PLC, a pump controller, a VSD, an HMI or a SCADA system. The controller then knows the real number and can start, stop or ramp the pump on its own. Four milliamps is the bottom of the transducer range. Twenty milliamps is the top. A 0-25 bar transducer sitting at 12mA is reading about 12.5 bar. The reason industry settled on this and stayed there is simple. If a cable is cut or a transducer dies, the loop drops to zero, not to 4mA. The controller can tell the difference between a real reading of nothing and a broken transducer. A voltage transducer cannot do that, and voltage also sags over a long cable run. On a bore 400 metres from the shed, a 4-20mA transducer still reads correctly at the far end.

Transducer Accuracy Is Where Cheap Units Fall Over

Most people compare transducers on price and pressure range. The number that actually decides whether you are happy in two years is accuracy, written as a percentage of full scale. Our transducer range is 0.5% FS. A lot of the general purpose gear sold into Australian pump work sits at 1.0% FS. On a 25 bar transducer that difference is 0.125 bar against 0.25 bar. It sounds small on paper. On a variable speed pump holding setpoint, a transducer with double the error means the drive hunts, the pump cycles more, and you wear out a mechanical seal early. Repeatability matters just as much. A transducer that reads 6.00 bar this morning and 6.00 bar next winter is doing its job. One that drifts with temperature is quietly lying to your controller. Every transducer we stock is temperature rated from -20°C to +80°C, which covers a Pilbara summer and a Wheatbelt frost with room left over.

PWP310C Pressure Transducer, 0-10, 0-16 and 0-25 Bar

The PWP310C is our general purpose pressure transducer and it is the one most people need. It reads line pressure and reports it as 4-20mA. Three ranges cover nearly everything: PWP310C10 for 0-10 bar, PWP310C16 for 0-16 bar, and PWP310C25 for 0-25 bar. All three are $195. Every PWP310C transducer shares the same build. Two-wire 4-20mA output. 12-30VDC loop powered, so the same pair of wires carries power and signal and you are not running a separate supply to the transducer. A 1/4 inch NPT male pressure port. A two metre direct cable outlet. SS316L stainless body. IP66. 0.5% FS accuracy. Overload protection at 1.5 times full scale, so a water hammer spike will not destroy the transducer. Pick the transducer range that puts your normal working pressure in the middle of the scale, not at the very top. A domestic or light commercial pressure system running at 4 to 5 bar is a clean fit for the 0-10 bar transducer. A commercial booster set or a long irrigation main is usually 0-16 bar. Reticulation off a deep bore, high rise boosting, and industrial pipeline duty go to the 0-25 bar transducer. Sizing a transducer too high throws away resolution. Sizing it too low means you clip the top and lose the reading exactly when you need it. These transducers are at home in HVAC and chiller plant, pump control panels, air conditioning systems, process automation, fire pump monitoring, and general pipeline work.

PWP416 Submersible Level Transducer, 0-4m and 0-10m

The submersible level transducer is a different animal and solves a different problem. Instead of reading pressure in a pipe, this transducer hangs in the liquid and measures the head of water above it, which tells you the depth. It is how you get a real tank level, a real bore standing water level, or a real sump level into a controller. Inside is a German piezoresistive sensing element in a 316L stainless housing, with an anti-clog weight protection base so the transducer sits properly and the diaphragm does not blind up in dirty water. Four options:

• PWP416, 0-4m range, 10m cable, $698
• PWP416430, 0-4m range, 30m cable, $810
• PWP41610, 0-10m range, 10m cable, $698
• PWP4161030, 0-10m range, 30m cable, $810

Range and cable length are two separate decisions and people mix them up. Range is how deep the water gets above the transducer. Cable is how far the transducer has to hang below your junction box or panel. A 3 metre poly tank needs a 0-4m transducer, but if the panel is on the shed wall 20 metres away you still want the 30m cable. Order a transducer with cable that is too short and you cannot splice it without wrecking the vent tube and the IP rating. Once a submersible level transducer is feeding a controller you can do the things that actually save money. Automatic pump-off protection so a bore pump never runs dry. Tank top-up on real level instead of a float that sticks. Alarms on high level in a sump before it goes over the top. Level trending so you can see a bore drawing down over a season.

Bore Water, Chloride and Why SS316L Is Not Optional

Groundwater across the Perth basin, the Wheatbelt and the Goldfields carries real salinity. Chloride attacks 304 stainless and pits it. A transducer with a 304 body or a plated brass port will look fine for a season and then start reading nonsense as the wetted parts corrode. Everything in this transducer range uses SS316L for the wetted parts, which is the grade that handles chloride. It is the same reason bore pump specifiers keep asking for 316 pump ends in the Wheatbelt and the Mid West. Heat is the other one. A transducer bolted to a pipe in an uninsulated shed near Kalgoorlie or Karratha spends summer well above ambient. Our transducer range is rated to +80°C, so it stays inside spec instead of drifting.

Why Buy Your Transducer From Pumptastic

The Price Is On The Page

This is the part of the market that frustrates people most. Search for an industrial transducer in Australia and you land on page after page of specification with no price, a Find A Partner button, or an enquiry form. You send an email. You wait two days. Then you get a number. Every transducer in this collection has a price on it and an add to cart button. $195 for a PWP310C pressure transducer. $698 or $810 for a submersible level transducer depending on cable. You can compare it, budget it, put it on a job sheet and buy it without speaking to anyone. If you would rather talk it through first, we are happy to, but you should not have to.

Stock, Not Backorder

A transducer is almost never a planned purchase. Something has failed, a pump is cycling, a controller is reading rubbish, and the job is stopped. There is not much point being the cheapest transducer supplier in Australia if the item ships in three weeks. We hold this transducer range in stock and dispatch fast, with free shipping Australia-wide over $100.

We Know What The Transducer Plugs Into

Pumptastic is a pump specialist with over 3,000 pumps and parts, not a general electrical wholesaler. When you ring about a transducer we can talk about the pump on the other end of it. Which controller it pairs with. Whether your VSD wants 4-20mA or 0-10V. Whether you need a level transducer or whether a float switch will do the job for a third of the money. That last one costs us a sale sometimes and we say it anyway.

Pair your transducer with our pressure control components and pump controllers. For level work, the level control components and float switches sit alongside a submersible transducer. Running a bore? A level transducer is what gives dry run protection to a Grundfos SQ and SQE pump or a Grundfos SP borehole pump. Building a full pressure system? Add a pressure tank and browse the automation and control range. Our stainless steel BSP fittings cover the adaptor if your tapping is BSP and the transducer port is NPT.

Not Sure Which Transducer You Need

Picking the wrong transducer range or the wrong cable length is the most common and most expensive mistake in this category, because you usually find out after the install. Call us on (08) 6384 5884, Monday to Friday, 9am to 5pm, or get in touch here. Tell us the pump, the pressure or the depth, and what the transducer is wiring into. We will tell you which one to buy, and we will tell you if you do not need a transducer at all.
