The Davey CS32‑160/2.2 is an end suction close‑coupled centrifugal pump with a full 316 stainless steel wet end, designed for clean water transfer. It delivers a maximum flow of 28.8 m³/h and a maximum head of 38 m. The high‑temperature mechanical seal (carbon/silicon carbide/EPDM) supports liquids from -20 °C to +110 °C. The pump features a patented floating neck ring, 360° volute flaring, and a back pull‑out design for easy servicing without disconnecting pipework. Supplied on a 304 stainless steel base with DIN (EN733) companion flanges. The motor is single‑phase, 2.2 kW, 240 V, 50 Hz, IP55, with 6205‑ZZ bearings.
Suitable Applications
- Vineyards and horticultural irrigation
- Dairy washdown
- Chiller water pumping
- Hot water washing
- Treated water transfer
- Small industrial processes
Key Specifications
| Product Name | Davey CS32‑160/2.2 Single Phase End Suction Centrifugal Pump |
|---|---|
| Product Number | CS32160-2.2/1 |
| EAN | — |
| Pump Type | End suction close‑coupled centrifugal pump, DIN (EN733) |
| Rated Flow | 28.8 m³/h (480 L/min) |
| Rated Head | 38 m |
| Maximum Head | 38 m |
| Speed (Pump Data) | 2870 rpm |
| Stages / Impellers | 1 |
| Reduced-Diameter Impellers | — |
| Shaft Seal | Mechanical seal: carbon / silicon carbide / EPDM |
| Liquid Temperature Range | -20 °C to +110 °C |
| Maximum Operating Pressure | 10 bar (1000 kPa) |
| Connections | DN 32 (32 mm) outlet, DIN (EN733) companion flanges |
| Base / Head Material | 304 stainless steel base, cast iron bell housing |
| Impeller Material | 316 stainless steel |
| Bearing | Drive end & non‑drive end: 6205‑ZZ |
| Motor Power (P2) | 2.2 kW |
| Voltage | 240 V |
| Frequency | 50 Hz |
| Rated Current | 11.27 A |
Documentation & Downloads
| CS Series End Suction Pumps Datasheet | Download |
| CS Series 316SS End Suction Pumps Datasheet | Download |
| CS Series Installation & Operating Instructions | Download |
