Tsurumi LSP Series Electric Residue Pump – LSP1.4S
📢 For orders over $100, FREE Shipping Australia-wide
Warranty: Manufacturer’s Warranty
The Tsurumi LSP1.4S is a single-phase portable self‑priming residue drainage pump incorporating a submersible motor, designed for fast removal of standing water down to floor level via the supplied 5m suction hose and attachment. Its flow‑thru design provides maximum motor cooling efficiency, allowing continuous operation at low water levels and extended dry‑run capability. The pump features dual inside mechanical seals (upper: ceramic + carbon; lower: SiC + ceramic) isolated in an oil chamber with an Oil Lifter for enhanced lubrication, an anti‑wicking cable entry, a siphon breaker to prevent reverse‑flow, and a miniature thermal protector (MTP) for overheat protection. This Australian version is rated for 50Hz operation (240V supply) and is well‑suited for construction, mining, industrial, and emergency dewatering across Australia and other 50Hz regions.
Suitable Applications
- Final clean‑up after standard dewatering
- Draining shallow pits, tanks, and basins
- Flood response and emergency water removal
- Commercial and residential clean‑ups
- Tight‑access areas where larger pumps won't fit
- Mining and construction site dewatering
Key Specifications
| Product Name | LSP1.4S |
| Pump Type | Self‑priming residue drainage pump with submersible motor |
| Suction × Discharge Bore | 25 mm × 25 mm (hose coupling with union) |
| Motor Output | 0.48 kW |
| Phase | Single‑phase |
| Starting Method | Capacitor Run |
| Speed | 3000 min⁻¹ (at 50Hz) |
| Maximum Head | 6.9 m (50Hz) |
| Maximum Capacity | 50 L/min (0.83 L/sec) |
| Maximum Vacuum | 73.3 kPa (550 mmHg) |
| Minimum Water Level | 3 mm (with suction attachment) |
| Shaft Seal | Dual inside mechanical seals (Upper: Ceramic + Carbon; Lower: SiC + Ceramic) with Oil Lifter |
| Liquid Temperature Range | 0 to 40°C |
| Connections | 25 mm suction × 25 mm discharge (hose coupling with union) |
| Impeller Material | Urethane rubber (vortex design) |
| Casing Material | Aluminium alloy / synthetic rubber |
| Bearing | Deep‑groove, double‑shielded C3 ball bearings (permanently lubricated) |
| Supply Voltage (Australia) | 240V (50Hz) |
| Rated Current (at 240V 50Hz) | 2.7 A |
| Enclosure Class | IP68 |
| Insulation Class | E |
| Motor Protection | MTP (Miniature Thermal Protector) – embedded in winding, cuts on overheat |
| Lubricating Oil | Turbine Oil (ISO VG32), 150 ml |
| Shaft Material | 403 Stainless Steel |
| Cable | H07RN‑F, 10m, with plug (Australian plug type not specified) |
| Automatic Control | None (manual operation) |
| Stand Material | Rubber stand (prevents floor scratching) |
| Dry Weight (excluding cable) | 16.5 kg |
Documentation & Downloads
| Single‑phase Portable Pumps Catalogue (LB/HS/HSD/LSC/LSP Series) | Download |
| LSP Series Product Guide | Download |
