Grundfos CRN 1-13 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 96520649 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96520649
Original price
$2,329.94
-
Original price
$2,329.94
Original price
$2,329.94
$2,329.94
-
$2,329.94
Current price
$2,329.94
📢 For orders over $100, FREE Shipping Australia-wide
The CRN 1-13 A-CA-A-V-HQQV is a vertical, non-self-priming, multistage in-line centrifugal pump designed for installation in pipe systems or on a foundation. With suction and discharge ports on the same level, it is optimized for compact configurations. Key components in contact with the liquid—impellers, intermediate chambers, and outer sleeve—are high-grade stainless steel (EN 1.4401 / AISI 316), while the pump head cover and base are stainless steel EN 1.4408. The pump features a single HQQV shaft seal, FlexiClamp pipe connections, and a high-efficiency IE3 three-phase AC motor.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1-13 A-CA-A-V-HQQV |
| Product Number | 96520649 |
| EAN | 5700396823638 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 61.3 m |
| Maximum Head | 80.7 m |
| Pump Speed (Data Basis) | 2864 rpm |
| Stages / Impellers | 13 / 13 |
| Shaft Seal | Single, HQQV |
| Liquid Temperature Range | -20 to 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connection Type | FlexiClamp |
| Inlet / Outlet | DN 32 (1 1/4") |
| Pressure Rating | PN 25 |
| Flange Size for Motor | FT100 |
| Impeller Material | Stainless Steel EN 1.4401 (AISI 316) |
| Pump Head / Base | Stainless Steel EN 1.4408 (AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 0.75 kW |
| Voltage | 3 × 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 3.30 / 1.90 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 80.7 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| Minimum Efficiency Index (MEI) | ≥ 0.70 |
| Net Weight | 23.7 kg |
| Gross Weight | 26.5 kg |
| Shipping Volume | 0.074 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
