Grundfos CR 64-2-2 A-F-A-E-HQQE Vertical Multistage Pump – 96123528 (3 x 380-415D/660-690YD)
by Grundfos
SKU 96123528
Original price
$5,702.81
-
Original price
$5,702.81
Original price
$5,702.81
$5,702.81
-
$5,702.81
Current price
$5,702.81
📢 For orders over $100, FREE Shipping Australia-wide
Grundfos CR 64-2-2 A-F-A-E-HQQE is a vertical, non-self-priming, multistage in-line centrifugal pump designed for installation in pipe systems and mounting on a foundation. The pump features a cast iron head and base, stainless steel (EN 1.4301 / AISI 304) impellers and intermediate chambers, a single HQQE mechanical shaft seal (EN 12756), and DIN PN16 flange connections. Power transmission is via a cast iron split coupling, driven by a 7.5 kW IE3 IEC three-phase motor.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and district cooling
- Industrial heating and cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Process liquids transfer
- Machining
- Wash and clean systems
- Desalination
- Reverse osmosis water treatment
- Drinking water treatment (WRAS, ACS approved)
- Surface water intake
- Water distribution
- Community water supply
- Groundwater transfer
- Irrigation (pivot, rotor & spray)
- Solar water solutions and boosting
- Controls and digital groundwater management
- Agriculture solar fertigation and dosing
- Livestock watering with solar solutions
Key Specifications
| Product Name | CR 64-2-2 A-F-A-E-HQQE |
| Product Number | 96123528 |
| EAN | 5700396697383 |
| Pump Type | Vertical multistage in-line centrifugal |
| Rated Flow | 64 m³/h |
| Rated Head | 29.2 m |
| Maximum Head | 40.8 m |
| Speed (Pump Data) | 2919 rpm |
| Stages / Impellers | 2 / 2 |
| Reduced-Diameter Impellers | 2 |
| Shaft Seal | Single HQQE (EN 12756) |
| Liquid Temperature Range | -30 °C to +120 °C |
| Maximum Operating Pressure | 16 bar |
| Connections | DN 100 / DN 100, DIN, PN 16 |
| Base / Head Material | Cast iron (EN-GJS-500-7 / ASTM A536 80-55-06) |
| Impeller Material | Stainless steel EN 1.4301 (AISI 304) |
| Bearing | SIC / Graflon support bearing |
| Motor Power (P2) | 7.5 kW |
| Voltage | 3 × 380-415D / 660-690Y V |
| Frequency | 50 Hz |
| Rated Current | 14.4–14.0 / 8.30–8.10 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 90.1–90.4 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 117 kg / 140 kg |
| Shipping Volume | 0.309 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, WRAS, ACS |
Documentation & Downloads
| Product Data Sheet (PDF) | Download |
