Grundfos CR 15-5 A-F-A-E-HQQE Vertical Multistage Pump – 96501896 (3 x 380-415DV)
by Grundfos
SKU 96501896
Original price
$3,201.69
-
Original price
$3,201.69
Original price
$3,201.69
$3,201.69
-
$3,201.69
Current price
$3,201.69
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 15-5 A-F-A-E-HQQE is a vertical, non-self-priming, multistage, in-line centrifugal pump designed for installation in pipe systems and mounting on a foundation. Suction and discharge ports are positioned on the same level for easy integration. The pump head and base are manufactured from cast iron, while all other wetted parts are in stainless steel (EN 1.4301), making it suitable for demanding commercial, industrial, and water supply applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis – water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment, fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product No. | 96501896 |
| Pump Type | Vertical multistage centrifugal |
| Rated Flow | 17 m³/h |
| Rated Head | 55.4 m |
| Maximum Head | 70.6 m |
| Stages | 5 |
| Impellers | 5 |
| Pump Orientation | Vertical |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQE |
| Base Material | Cast iron (EN-GJL-200 / ASTM A48-25B) |
| Impeller Material | Stainless steel EN 1.4301 (AISI 304) |
| Bearing Material | SIC |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Type | DIN flanges |
| Inlet / Outlet Size | DN 50 / DN 50 |
| Pressure Rating | PN 25 |
| Motor Type | IEC 112MC, 3-phase |
| Rated Power (P2) | 4 kW |
| Rated Voltage | 3 × 380–415 V, 50 Hz |
| Rated Speed | 2920–2940 rpm |
| IE Efficiency Class | IE3 |
| Enclosure Class | IP55 |
| Insulation Class | F |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Minimum Efficiency Index (MEI) | ≥ 0.70 |
| Net Weight | 74 kg |
Documentation & Downloads
| Product Data Sheet (CR 15-5 A-F-A-E-HQQE, Product No. 96501896) | Download PDF |
