Ebara 2CDX 200/50 Twin Impeller Centrifugal Pump – 199950-0004 – 3.7 kW – 400V – 3 Phase
📢 For orders over $100, FREE Shipping Australia-wide
The Ebara 2CDX 200/50 is a three-phase, twin impeller centrifugal pump designed for domestic water supply and pressure boosting applications requiring the highest flow rates and heads in the 2CDX range. Constructed with a robust AISI 304 stainless steel pump casing, twin impellers, and diffuser, this unit features a carbon/ceramic/NBR mechanical seal for reliable performance. The pump has a maximum liquid temperature of 60°C and a maximum working pressure of 8 bar. This model features a larger 40 mm suction size (G1½") for increased flow capacity. The motor bracket is constructed from cast iron for enhanced durability. Three phase motors require external overload protection to be provided by the installer.
Suitable Applications
- Domestic water supply and pressure boosting
- Small-scale garden irrigation
- Water transfer from tanks and wells
- Heating, ventilation, air-conditioning and cooling
- Handling of clean water in general
- Washing plants and membrane filtration
- Cooling towers
- Sprinkler and flow irrigation
- Beverage processing and pharmaceutical services
Key Specifications
| Product Name | 2CDX 200/50 |
| Product Number | 199950-0004 |
| Pump Type | Twin Impeller Centrifugal Pump (Closed impellers) | Discharge / Suction Size | 25 mm / 40 mm (G1" discharge, G1½" suction) |
| Motor Power (P2) | 3.7 kW (5.0 HP) |
| Voltage | 400V | Phase | Three phase (3 ph) |
| Maximum Flow Rate | Up to 12.6 m³/h |
| Maximum Head | Up to 75 m |
| Maximum Liquid Temperature | 60°C (110°C with optional high temperature seal) |
| Minimum Liquid Temperature | -5°C |
| Maximum Working Pressure | 8 bar |
| Connections | Suction: G1½" (UNI ISO 228); Discharge: G1" (UNI ISO 228) |
| Pump Casing Material | AISI 304 Stainless Steel |
| Impeller Material | AISI 304 Stainless Steel (Twin closed type) |
| Diffuser Material | AISI 304 Stainless Steel |
| Shaft Material (wetted parts) | AISI 304 Stainless Steel |
| Shaft Seal | Standard: Carbon/Ceramic/NBR |
| Motor Efficiency Class | IE2 (Three phase, from 0.75 kW up to 4.0 kW) |
| Number of Poles | 2 |
| Protection Degree | IP55 |
| Insulation Class | F |
| Motor Bracket Material | Cast iron |
| Optional High Temperature Seal | Carbon/Ceramic/Viton with Viton O-rings (max 110°C) |
| Optional Hard Faced Seal | Silicon Carbide/Silicon Carbide/Viton with Viton O-rings (max 110°C) | Net Weight | 36 kg |
| Gross Weight (Packed) | 37.5 kg |
| Packing Dimensions (W x D x H) | 244 x 313 x 507 mm |
| Warranty | 2 years (Parts & Labour) |
| Approvals | CE |
Performance Data
| Flow Rate (L/min) | 0 | 50 | 80 | 120 | 150 | 180 | 210 |
| Flow Rate (m³/h) | 0 | 3.0 | 4.8 | 7.2 | 9.0 | 10.8 | 12.6 |
| Total Head (m) | — | — | 71.5 | 70.1 | 67.0 | 64.3 | 61.2 |
