Grundfos CRN 1-27 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92901357 (1 x 220-230 V)
by Grundfos
SKU 92901357
Original price
$4,323.69
-
Original price
$4,323.69
Original price
$4,323.69
$4,323.69
-
$4,323.69
Current price
$4,323.69
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal inline pump designed for high-pressure applications with suction and discharge ports on the same level. All wetted components are made of high-grade stainless steel (EN 1.4401 / AISI 316), ensuring excellent corrosion resistance and durability. The pump is equipped with a reliable HQQV cartridge shaft seal for safe operation and simplified maintenance. Power transmission is via a rigid split coupling, and pipe connections utilize combined DIN-ANSI-JIS flanges. Driven by a 1-phase, fan-cooled IEC asynchronous motor (90SE), this model supports higher head performance with increased motor capacity.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1-27 A-FGJ-A-V-HQQV |
| Product Number | 92901357 |
| EAN | 5715121283861 |
| Pump Type | Vertical, Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 117.8 m |
| Maximum Head | 163.2 m |
| Speed (Pump Data) | 2767 rpm |
| Stages / Impellers | 27 / 27 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV Cartridge |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4") DIN / ANSI / JIS, PN 25 / 300 lb |
| Flange Size for Motor | FT115 |
| Base / Head Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 1.5 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 8.75–9.10 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 81.3 % |
| Enclosure Class | IP55 Dust/Jetting |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 43.9 / 46.8 kg |
| Shipping Volume | 0.13 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| CRN 1-27 A-FGJ-A-V-HQQV Datasheet | Download |
