Grundfos SP 14-11 Submersible Borehole Pump – 98809287 (3 x 415V, MS4000 Motor)
by Grundfos
SKU 98809287
Original price
$3,369.09
-
Original price
$3,369.09
Original price
$3,369.09
$3,369.09
-
$3,369.09
Current price
$3,369.09
📢 For orders over $100, FREE Shipping Australia-wide
Submersible borehole pump, suitable for pumping clean water. Can be installed vertically or horizontally. All steel components are made in stainless steel, EN 1.4301 (AISI 304), that ensures high corrosive resistance. This pump carries drinking water approval.
Key Specifications:
| Product Name | SP 14-11 |
| Product No. | 98809287 |
| EAN | 5712601664332 |
| Rated Flow | 14 m³/h |
| Rated Head | 47.3 m |
| Stages | 11 |
| Motor Type | MS4000 (3-phase) |
| Rated Power | 3 kW |
| Voltage / Frequency | 3 × 380-400-415 V / 50 Hz |
| Rated Current | 7.7-8.1 A |
| Starting Current | 430-460 % |
| Power Factor | 0.86-0.77 |
| Rated Speed | 2830-2870 rpm |
| Start Method | Direct-on-line |
| Enclosure / Insulation Class | IP68 / Class F |
| Liquid Temperature Range | -15 °C to 40 °C |
| Max Operating Pressure | 60 bar |
| Connection Size | Rp 2 inch |
| Minimum Borehole Diameter | 105 mm |
| Material | Stainless Steel EN 1.4301 (AISI 304) |
| Net Weight | 29.7 kg |
Documentation & Downloads:
| Document | Download |
|---|---|
| Flow Sleeves (Quick Guide) | 📄 Download PDF |
| Pt100, Pt1000 (Quick Guide) | 📄 Download PDF |
| Cathodic Protection (Quick Guide) | 📄 Download PDF |
| SP (Safety Instructions) | 📄 Download PDF |
| SP (Installation & Operation Instructions) | 📄 Download PDF |
| SP A, SP – Submersible Pumps, Motors & Accessories (Data Booklet) | 📄 Download PDF |
