Grundfos SP 14-6 Submersible Borehole Pump – 98699354 (3 x 415V, MS402 Motor)
by Grundfos
SKU 98699354
Original price
$1,959.44
-
Original price
$1,959.44
Original price
$1,959.44
$1,959.44
-
$1,959.44
Current price
$1,959.44
📢 For orders over $100, FREE Shipping Australia-wide
Grundfos SP 14-6 is a stainless-steel submersible borehole pump designed for pumping clean water. It can be installed vertically or horizontally and is built with high corrosion resistance using stainless steel (EN 1.4301 / AISI 304). This pump is approved for drinking water applications and offers reliable performance for domestic, agricultural, and industrial water supply systems. The pump is fitted with a 1.5 kW MS402 motor featuring sand shield, lip seal, water-lubricated bearings, and a volume compensating diaphragm for durability and efficiency.
Key Specifications:
| Product name | SP 14-6 |
| Product No. | 98699354 |
| Rated flow | 14 m³/h |
| Rated head | 25.3 m |
| Stages | 6 |
| Power required | 1.5 kW |
| Motor type | MS402 (NEMA) |
| Enclosure class | IP68 |
| Material | Stainless steel EN 1.4301 / AISI 304 |
| Net weight | 19.7 kg |
Documentation & Downloads:
| Document | Download |
|---|---|
| SP (Safety instructions) | 📄 Download PDF |
| SP (Installation & Operating Instructions) | 📄 Download PDF |
| SP A, SP - Submersible Pumps, Motors & Accessories (Data Booklet) | 📄 Download PDF |
| SP Accessories (Data Booklet) | 📄 Download PDF |
| SP (Recommended Spare Parts) (Service Kit Catalogue) | 📄 Download PDF |
