Grundfos SP 14-6 Submersible Borehole Pump - 98699340 (1 x 240V, MS402/CSCR Motor)
by Grundfos
SKU 98699340
Original price
$2,049.62
-
Original price
$2,049.62
Original price
$2,049.62
$2,049.62
-
$2,049.62
Current price
$2,049.62
📢 For orders over $100, FREE Shipping Australia-wide
Grundfos SP 14-6 is a stainless-steel submersible borehole pump designed for pumping clean water. It can be installed vertically or horizontally and is built with high corrosion resistance using stainless steel (EN 1.4301 / AISI 304). This pump is approved for drinking water applications and offers reliable performance for domestic, agricultural, and industrial water supply systems. The pump is fitted with a 1.5 kW MS402 motor featuring sand shield, lip seal, water-lubricated bearings, and a volume compensating diaphragm for durability and efficiency.
Key Specifications:
| Product name | SP 14-6 |
| Product No. | 98699340 |
| Rated flow | 14 m³/h |
| Rated head | 25.3 m |
| Stages | 6 |
| Power required | 1.5 kW |
| Motor type | MS402 (NEMA) |
| Rated voltage | 1 x 240 V (Single-phase) |
| Rated current | 9.8 A |
| Enclosure class | IP68 |
| Material | Stainless steel EN 1.4301 / AISI 304 |
| Net weight | 20.2 kg |
Documentation & Downloads:
| Document | Download |
|---|---|
| Flow Sleeves (Quick Guide) | 📄 Download PDF |
| Pt100, Pt1000 (Quick Guide) | 📄 Download PDF |
| Cathodic protection (Quick Guide) | 📄 Download PDF |
| SP (Safety instructions) | 📄 Download PDF |
| SP (Installation & Operating Instructions) | 📄 Download PDF |
| SP A, SP - Submersible Pumps, Motors & Accessories (Data Booklet) | 📄 Download PDF |
| SP Accessories (Data Booklet) | 📄 Download PDF |
| SP (Recommended Spare Parts) (Service Kit Catalogue) | 📄 Download PDF |
