Grundfos CRN 5-8 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902593 (1 x 220-230V)
by Grundfos
SKU 92902593
Original price
$2,736.25
-
Original price
$2,736.25
Original price
$2,736.25
$2,736.25
-
$2,736.25
Current price
$2,736.25
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 5-8 is a vertical multistage centrifugal pump designed for high-pressure water transfer in commercial and industrial systems. Constructed with high-grade stainless steel (EN 1.4401 / AISI 316) for all wetted components, it ensures durability and corrosion resistance. The pump delivers a rated flow of 5.8 m³/h and a maximum head of 54 m, making it suitable for demanding applications. It features a reliable HQQV cartridge shaft seal, FlexiClamp (CA) connections for easy installation, and a 1-phase, fan-cooled IEC motor (1.1 kW, IE2 efficiency) for efficient and stable operation.
Suitable Applications
- Commercial water pressure boosting
- Industrial water supply and transfer
- Water treatment and reverse osmosis systems
- Irrigation and agricultural water supply
- District heating and cooling systems
- Wash and clean systems
- Solar water supply and boosting solutions
Key Specifications
| Product Name | CRN 5-8 A-CA-A-V-HQQV |
| Product Number | 92902593 |
| EAN | 5715121303651 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 37.8 m |
| Maximum Head | 54 m |
| Speed (Pump Data) | 2789 rpm |
| Stages / Impellers | 8 / 8 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV (Single, Cartridge) |
| Liquid Temperature Range | -20 to 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1 1/4"), FlexiClamp (CA), PN 25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 1.1 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 6.60–6.30 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 79.6 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.57 |
| Net / Gross Weight | 32 / 36.1 kg |
| Shipping Volume | 0.092 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
