Grundfos CRN 5-5 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902590 (1 x 220-230V)
by Grundfos
SKU 92902590
Original price
$2,398.69
-
Original price
$2,398.69
Original price
$2,398.69
$2,398.69
-
$2,398.69
Current price
$2,398.69
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal inline pump with suction and discharge ports on the same level. All wetted components are made from high-grade stainless steel (EN 1.4401 / AISI 316) for superior corrosion resistance. The pump is equipped with a reliable HQQV cartridge shaft seal, FlexiClamp connections (DN 32 / 1¼", PN 25), and a 1-phase, fan-cooled IEC asynchronous motor, ensuring efficient and dependable performance in demanding applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 5-5 A-CA-A-V-HQQV |
| Product Number | 92902590 |
| EAN | 5715121303590 |
| Pump Type | Vertical, Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 21.7 m |
| Maximum Head | 32 m |
| Speed (Pump Data) | 2759 rpm |
| Stages / Impellers | 5 / 5 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV Cartridge (Single) |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1¼") FlexiClamp, PN 25 |
| Base / Head Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.75 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 4.60-4.75 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 77.4% |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.57 |
| Net / Gross Weight | 22 / 24.8 kg |
| Shipping Volume | 0.063 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| CRN 5-5 A-CA-A-V-HQQV Datasheet | Download |
