Grundfos CRN 5-3 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902588 (1 x 220-230V)
by Grundfos
SKU 92902588
Original price
$2,004.75
-
Original price
$2,004.75
Original price
$2,004.75
$2,004.75
-
$2,004.75
Current price
$2,004.75
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal pump with inlet and outlet ports on the same level (inline). Pump components in contact with the liquid are made from high-grade stainless steel (EN 1.4401 / AISI 316). The pump features a cartridge shaft seal for reliability and easy maintenance, FlexiClamp connections, and a 1-phase, fan-cooled asynchronous motor.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 5-3 A-CA-A-V-HQQV |
| Product Number | 92902588 |
| EAN | 5715121303552 |
| Pump Type | Vertical, Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 13.4 m |
| Maximum Head | 20.4 m |
| Speed (Pump Data) | 2750 rpm |
| Stages / Impellers | 3 / 3 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV Cartridge |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 / 1¼" FlexiClamp, PN 25 |
| Base / Head Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.55 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 3.70-3.75 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 74.1% |
| Enclosure Class | IP55 Dust/Jetting |
| Insulation Class | F |
| MEI | 0.57 |
| Net / Gross Weight | 20.9 / 23.7 kg |
| Shipping Volume | 0.063 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| CRN 5-3 A-CA-A-V-HQQV Datasheet | Download |
