Grundfos CRN 5-20 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 96532697 (3 x 220-240D/380-415YV)

SKU 96532697
Original price $4,292.06 - Original price $4,292.06
Original price
$4,292.06
$4,292.06 - $4,292.06
Current price $4,292.06

📢 For orders over $100, FREE Shipping Australia-wide

The Grundfos CRN 5-20 A-CA-A-V-HQQV is a vertical, non-self-priming, multistage in-line centrifugal pump for pipe system or foundation installation. Featuring 20 stainless steel impellers (EN 1.4401 / AISI 316), a HQQV cartridge shaft seal, and FlexiClamp (CA) DN 32 connections, it is powered by a 3-phase IEC 100LC motor (3 kW). This pump delivers high-efficiency operation up to 136.1 m head, making it suitable for industrial, commercial, agricultural, and solar water applications.

Suitable Applications

  • Commercial heating and air conditioning
  • Commercial water pressure boosting
  • Industrial water supply, wastewater, and process water treatment
  • Desalination and reverse osmosis
  • Water distribution, irrigation, and solar water solutions
  • Agriculture, livestock watering, fertigation, and solar boosting solutions

Key Specifications

Product Name CRN 5-20 A-CA-A-V-HQQV
Product Number 96532697
EAN 5700397403808
Pump Type Vertical Multistage Centrifugal
Rated Flow 5.8 m³/h
Rated Head 102.9 m
Maximum Head 136.1 m
Speed (Pump Data) 2902 rpm
Stages / Impellers 20 / 20
Shaft Seal HQQV
Liquid Temperature Range -20 .. 90 °C
Maximum Operating Pressure 25 bar
Connections DN 32 (1¼") inlet/outlet, FlexiClamp (CA), PN 25
Base / Head Material Stainless steel (EN 1.4408 / AISI 316)
Impeller Material Stainless steel (EN 1.4401 / AISI 316)
Bearing SIC
Motor Power (P2) 3 kW
Voltage 3 x 220-240D / 380-415Y V
Frequency 50 Hz
Rated Current 11.0 / 6.30 A
Motor Efficiency Class IE3
Motor Efficiency (Full Load) 87.1 %
Enclosure Class IP55
Insulation Class F
Built-in Motor Protection PTC
MEI ≥ 0.57
Net / Gross Weight 47.1 / 52.4 kg
Shipping Volume 0.133 m³
Approvals CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS

Documentation & Downloads

Grundfos CRN 5-20 A-CA-A-V-HQQV Datasheet Download
