Grundfos CRN 5-12 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902597 (1 x 220-230V)
by Grundfos
SKU 92902597
Original price
$3,722.13
-
Original price
$3,722.13
Original price
$3,722.13
$3,722.13
-
$3,722.13
Current price
$3,722.13
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 5-12 A-CA-A-V-HQQV is a vertical multistage centrifugal pump engineered for high-pressure industrial and commercial applications. Built with high-grade stainless steel (EN 1.4401 / AISI 316) for all wetted components, it ensures excellent corrosion resistance and long service life. The pump delivers a rated flow of 5.8 m³/h and a maximum head of 79.9 m. It features a durable HQQV cartridge shaft seal, FlexiClamp (CA) connections for fast and secure installation, and is driven by a 2.2 kW single-phase, fan-cooled asynchronous motor for efficient and reliable performance.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis
- Surface water intake
- Drinking water treatment and distribution
- Irrigation and agriculture (including solar solutions)
- Groundwater transfer and community water supply
Key Specifications
| Product Name | CRN 5-12 A-CA-A-V-HQQV |
| Product Number | 92902597 |
| EAN | 5715121303835 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 55.5 m |
| Maximum Head | 79.9 m |
| Speed (Pump Data) | 2730 rpm |
| Stages / Impellers | 12 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1 1/4"), FlexiClamp (CA), PN 25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 2.2 kW |
| Voltage | 1 x 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 13.1–12.6 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 83.2 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.57 |
| Net / Gross Weight | 39.1 / 43.1 kg |
| Shipping Volume | 0.092 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Data Sheet | Download |
