Grundfos CRN 3-8 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902224 (1 x 220-230V)
by Grundfos
SKU 92902224
Original price
$2,308.63
-
Original price
$2,308.63
Original price
$2,308.63
$2,308.63
-
$2,308.63
Current price
$2,308.63
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal pump with inline suction and discharge ports. Wetted parts are high-grade stainless steel (EN 1.4401 / AISI 316). Features a reliable HQQV cartridge shaft seal, FlexiClamp pipe connections (DN 32 / 1¼", PN 25), and a 1-phase, fan-cooled IEC 80B motor rated 0.75 kW, 220-230 V, 50 Hz, IP55.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 3-8 A-CA-A-V-HQQV |
| Product Number | 92902224 |
| EAN | 5715121296687 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 3 m³/h |
| Rated Head | 36.1 m |
| Maximum Head | 51.7 m |
| Speed (Pump Data) | 2759 rpm |
| Stages / Impellers | 8 / 8 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV Cartridge Seal |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1¼") FlexiClamp, PN 25 |
| Flange Size (Motor) | FT100 |
| Base / Head Material | Stainless steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.75 kW |
| Voltage | 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 4.75-4.60 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 77.4% |
| Enclosure Class | IP55 Dust/Jetting |
| Insulation Class | F |
| MEI | 0.70 |
| Net / Gross Weight | 22.5 / 25.2 kg |
| Shipping Volume | 0.063 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| CRN 3-8 A-CA-A-V-HQQV Datasheet | Download |
