Grundfos CRN 3-29 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902339 (1 x 220-230V)
by Grundfos
SKU 92902339
Original price
$4,734.13
-
Original price
$4,734.13
Original price
$4,734.13
$4,734.13
-
$4,734.13
Current price
$4,734.13
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 3-29 A-FGJ-A-V-HQQV is a vertical, multistage centrifugal pump designed for demanding water supply, pressure boosting, treatment, and industrial transfer duties. It features inline suction and discharge ports, wetted parts in high-grade stainless steel, a single HQQV cartridge shaft seal, and combined DIN / ANSI / JIS flange connections. This variant is fitted with a 2.2 kW single-phase IEC motor and is suitable for both commercial and industrial applications where high head performance is needed.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply and wastewater treatment
- Industrial process water treatment
- Desalination and reverse osmosis
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation and rotor & spray irrigation
- Solar water solutions
- Community water supply
- Ground water transfer
- Pivot irrigation
- Fertigation, dosing, and digital water management
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | Grundfos CRN 3-29 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902339 |
| Product Number | 92902339 |
| EAN Number | 5715121298889 |
| Pump Type | Vertical multistage centrifugal pump |
| Rated Flow | 3 m³/h |
| Rated Head | 124.6 m |
| Maximum Head | 184.6 m |
| Stages / Impellers | 29 / 29 |
| Pump Speed | 2730 rpm |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 .. 90 °C |
| Selected Liquid Temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Shaft Seal | HQQV |
| Shaft Seal Arrangement | Single |
| Materials | Base: EN 1.4408 / AISI 316, Impeller: EN 1.4401 / AISI 316, Bearing: SIC |
| Maximum Operating Pressure | 25 bar |
| Connection Type | DIN / ANSI / JIS |
| Connection Size | DN 25/32 (1 1/4 inch) |
| Pressure Rating | PN 25 |
| Flange Rating Inlet | 300 lb |
| Motor Standard | IEC |
| Motor Type | 90LD |
| Rated Power (P2) | 2.2 kW |
| Rated Voltage | 1 x 220-230 V |
| Mains Frequency | 50 Hz |
| Rated Current | 13.1-12.6 A |
| Rated Speed | 2860-2880 rpm |
| IE Efficiency Class | IE2 |
| Motor Protection | PTO |
| Enclosure Class | IP55 |
| Insulation Class | F |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Net Weight | 48.1 kg |
| Gross Weight | 53.5 kg |
| Shipping Volume | 0.133 m³ |
| Country of Origin | AU |
Documentation & Downloads
| Product PDF | Download PDF |
