Grundfos CRN 3-2 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 96520683 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96520683
Original price
$1,655.50
-
Original price
$1,655.50
Original price
$1,655.50
$1,655.50
-
$1,655.50
Current price
$1,655.50
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 3-2 is a vertical, multistage centrifugal inline pump designed for low- to medium-pressure applications in pipe systems or mounted on foundations. All wetted components, including impellers and intermediate chambers, are made of high-grade stainless steel (EN 1.4401 / AISI 316) with a stainless steel base and pump head cover (EN 1.4408 / AISI 316). The pump uses a HQQV cartridge shaft seal for reliability and easy service. FlexiClamp (CA) connections (DN 32, PN 25) simplify installation, and it is driven by a 0.37 kW 3-phase IEC 71A motor with IE3 efficiency and IP55 protection.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Machining and wash/clean systems
- Industrial process liquid transfer
- Industrial heating and cooling
- Industrial water supply and wastewater treatment
- Desalination and reverse osmosis systems
- Surface water intake and drinking water treatment
- Water distribution and irrigation
- Solar water solutions and boosting systems
- Community water supply and groundwater transfer
- Livestock watering and agricultural irrigation (pivot, fertigation, chemigation)
- Frost protection and municipal water systems
Key Specifications
| Product Name | CRN 3-2 A-CA-A-V-HQQV |
| Product Number | 96520683 |
| EAN | 5700396825304 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 3 m³/h |
| Rated Head | 9.6 m |
| Maximum Head | 13.5 m |
| Speed (Pump Data) | 2873 rpm |
| Stages / Impellers | 3 / 2 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV (Single) |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1 1/4"), FlexiClamp (CA), PN 25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 0.37 kW |
| Voltage | 3 x 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 1.74 / 1.00 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 73.8 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 16.5 / 19.1 kg |
| Shipping Volume | 0.054 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRN 3-2 Datasheet | Download |
