Grundfos CRN 3-19 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 96516863 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516863
Original price
$3,456.06
-
Original price
$3,456.06
Original price
$3,456.06
$3,456.06
-
$3,456.06
Current price
$3,456.06
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 3-19 A-FGJ-A-V-HQQV is a vertical, non-self-priming, multistage in-line centrifugal pump designed for high-demand commercial, industrial, water treatment, and irrigation applications. Constructed with high-grade stainless steel wetted parts and a single HQQV shaft seal, it provides reliable performance for clean water transfer, pressure boosting, and process liquid handling.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | Grundfos CRN 3-19 A-FGJ-A-V-HQQV |
| Product Number | 96516863 |
| EAN Number | 5700396751245 |
| Pump Type | Vertical multistage in-line centrifugal pump |
| Rated Flow | 3 m³/h |
| Rated Head | 92.5 m |
| Maximum Head | 125.8 m |
| Stages | 19 |
| Impellers | 19 |
| Number of Reduced-Diameter Impellers | 0 |
| Low NPSH | N |
| Pump Speed | 2896 rpm |
| Pump Orientation | Vertical |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQV |
| Code for Shaft Seal | HQQV |
| Pump Version | A |
| Model | A |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 to 90 °C |
| Selected Liquid Temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Base Material | Stainless steel, EN 1.4408 / AISI 316 |
| Impeller Material | Stainless steel, EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Material Code | A |
| Rubber Components Code | V (FKM) |
| Maximum Ambient Temperature | 60 °C |
| Maximum Operating Pressure | 25 bar |
| Max Pressure at Stated Temperature | 25 bar / 90 °C; 25 bar / -20 °C |
| Connection Type | DIN / ANSI / JIS |
| Connection Code | FGJ |
| Inlet Connection Size | DN 25/32 (1 1/4 inch) |
| Outlet Connection Size | DN 25/32 (1 1/4 inch) |
| Pressure Rating for Connection | PN 25 |
| Flange Rating Inlet | 300 lb |
| Flange Size for Motor | FT115 |
| Terminal Box Position | 6 |
| Motor Standard | IEC |
| Motor Type | 90SD |
| Rated Power (P2) | 1.5 kW |
| Power Required by Pump (P2) | 1.5 kW |
| Mains Frequency | 50 Hz |
| Rated Voltage | 3 x 220-240D/380-415Y V |
| Rated Current | 5.70/3.30 A |
| Starting Current | 750-820 % |
| Cos Phi / Power Factor | 0.84-0.78 |
| Rated Speed | 2890-2910 rpm |
| IE Efficiency Class | IE3 |
| Motor Efficiency at Full Load | 84.2 % |
| Motor Efficiency at 3/4 Load | 86.4-84.9 % |
| Motor Efficiency at 1/2 Load | 86.0-83.0 % |
| Number of Poles | 2 |
| Enclosure Class (IEC 34-5) | IP55 Dust/Jetting |
| Insulation Class (IEC 85) | F |
| Built-in Motor Protection | NONE |
| Motor No. | 85U01906 |
| Frequency Converter | None |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Approvals for Drinking Water | WRAS, ACS |
| Curve Tolerance | ISO9906:2012 3B |
| Minimum Efficiency Index (MEI) | ≥ 0.70 |
| Net Weight | 38.1 kg |
| Gross Weight | 42.1 kg |
| Shipping Volume | 0.092 m³ |
| Country of Origin | TW |
| Custom Tariff No. | 8413709062 |
| Price | AUD 5027 |
