Grundfos CRN 3-19 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902232 (1 x 220-230V)
by Grundfos
SKU 92902232
Original price
$3,746.88
-
Original price
$3,746.88
Original price
$3,746.88
$3,746.88
-
$3,746.88
Current price
$3,746.88
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal pump with inline suction and discharge ports. Pump materials in contact with the liquid are high-grade stainless steel (EN 1.4401 / AISI 316). Equipped with a cartridge shaft seal (HQQV) for high reliability and easy service, power transmission via rigid split coupling, and FlexiClamp connections. Fitted with a 1-phase, fan-cooled IEC 90SE motor, delivering 1.5 kW at 220-230 V, 50 Hz.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 3-19 A-CA-A-V-HQQV |
| Product Number | 92902232 |
| EAN | 5715121296847 |
| Pump Type | Vertical / Multistage Centrifugal |
| Rated Flow | 3 m³/h |
| Rated Head | 84.1 m |
| Maximum Head | 122 m |
| Speed (Pump Data) | 2767 rpm |
| Stages / Impellers | 19 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV Cartridge |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 / 1 1/4" FlexiClamp, PN 25 |
| Base / Head Material | Stainless steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 1.5 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 9.1-8.75 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 81.3 % |
| Enclosure Class | IP55 Dust/Jetting |
| Insulation Class | F |
| MEI | 0.70 |
| Net / Gross Weight | 36.5 / 40.6 kg |
| Shipping Volume | 0.092 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| CRN 3-19 A-CA-A-V-HQQV Product PDF | Download |
