Grundfos CRN 3-10 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902226 (1 x 220-230V)
by Grundfos
SKU 92902226
Original price
$2,476.38
-
Original price
$2,476.38
Original price
$2,476.38
$2,476.38
-
$2,476.38
Current price
$2,476.38
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 3-10 is a high-performance vertical multistage centrifugal inline pump engineered for high-pressure applications. Constructed entirely from high-grade stainless steel (EN 1.4401 / AISI 316) for all wetted components, it ensures superior corrosion resistance and durability. With a rated flow of 3 m³/h and a maximum head of 63.9 m, it is ideal for demanding systems. The pump features a reliable HQQV cartridge shaft seal and FlexiClamp (CA) connections for easy installation and maintenance. It is powered by a 0.75 kW single-phase, fan-cooled asynchronous motor (IEC, IE2), delivering efficient and stable operation across various commercial and industrial duties.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Machining and wash & clean systems
- Process liquid transfer
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis systems
- Surface water intake and distribution
- Drinking water treatment
- Irrigation and agricultural water supply
- Solar water solutions and boosting
- Groundwater transfer and pivot irrigation
- Livestock watering systems
Key Specifications
| Product Name | CRN 3-10 A-CA-A-V-HQQV |
| Product Number | 92902226 |
| EAN | 5715121296724 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 3 m³/h |
| Rated Head | 43.6 m |
| Maximum Head | 63.9 m |
| Speed (Pump Data) | 2759 rpm |
| Stages / Impellers | 10 / 10 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV (Single cartridge) |
| Liquid Temperature Range | -20 to 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1¼"), FlexiClamp (CA), PN 25 |
| Base / Head Material | Stainless Steel EN 1.4408 (AISI 316) |
| Impeller Material | Stainless Steel EN 1.4401 (AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 0.75 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 4.75–4.60 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 77.4 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 23.3 / 26.1 kg |
| Shipping Volume | 0.074 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
