Grundfos CRN 1S-19 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 96515948 (3 x 220-240D/380-415Y V)
by Grundfos
SKU 96515948
Original price
$2,753.44
-
Original price
$2,753.44
Original price
$2,753.44
$2,753.44
-
$2,753.44
Current price
$2,753.44
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, non-self-priming, multistage in-line centrifugal pump designed for pipe system installation or foundation mounting. All wetted parts—including impellers, intermediate chambers, and outer sleeve—are made of high-grade stainless steel (EN 1.4401), while pump head cover and base are stainless steel EN 1.4408. It features a single HQQV shaft seal (EN 12756), DIN/ANSI/JIS flanged connections, and a 3-phase IE3 AC motor delivering 0.9 m³/h rated flow, 73.4 m rated head, and maximum head of 110.1 m. Suitable for industrial, commercial, and water treatment applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1S-19 A-FGJ-A-V-HQQV |
| Product Number | 96515948 |
| EAN | 5700396734293 |
| Pump Type | Vertical / Multistage Centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 73.4 m |
| Maximum Head | 110.1 m |
| Speed (Pump Data) | 2856 rpm |
| Stages / Impellers | 19 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | Single, HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4 inch), DIN / ANSI / JIS, PN 25 / 300 lb |
| Base / Head Material | Stainless steel, EN 1.4408 / AISI 316 |
| Impeller Material | Stainless steel, EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.55 kW |
| Voltage | 3 x 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 2.50 / 1.44 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 77.8 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.54 |
| Net / Gross Weight | 26.5 / 30.6 kg |
| Shipping Volume | 0.092 m³ |
| Country of Origin | TW |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
