Grundfos CRN 1S-19 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92900028 (1 x 220-230V)
by Grundfos
SKU 92900028
Original price
$2,716.31
-
Original price
$2,716.31
Original price
$2,716.31
$2,716.31
-
$2,716.31
Current price
$2,716.31
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 1S-19 A-CA-A-V-HQQV is a vertical, inline multistage centrifugal pump with inlet and outlet ports on the same level. All wetted parts are made of high-grade stainless steel (EN 1.4401 / AISI 316), providing durability for demanding applications such as water treatment, irrigation, solar water solutions, and industrial processes. The pump features a single HQQV mechanical shaft seal, FlexiClamp connections, and a 0.55 kW single-phase IEC asynchronous motor. It delivers a rated flow of 0.9 m³/h with a rated head of 70.2 m and a maximum head of 103.6 m.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1S-19 A-CA-A-V-HQQV |
| Product Number | 92900028 |
| EAN | 5715121262262 |
| Pump Type | Vertical Multistage Centrifugal Pump |
| Rated Flow | 0.9 m³/h |
| Rated Head | 70.2 m |
| Maximum Head | 103.6 m |
| Speed (Pump Data) | 2750 rpm |
| Stages / Impellers | 19 Stages / 19 Impellers |
| Shaft Seal | HQQV (Single Mechanical Seal) |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connection Type | FlexiClamp |
| Connection Size | DN 32 (1 1/4 inch) |
| Pressure Rating | PN 25 |
| Base Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 0.55 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 3.70 – 3.75 A |
| Motor Efficiency Class | IE2 |
| Motor Speed | 2800 – 2820 rpm |
| Enclosure Class | IP55 |
| Insulation Class | F |
| Minimum Efficiency Index (MEI) | ≥ 0.54 |
| Net Weight | 26.7 kg |
| Gross Weight | 30.8 kg |
| Shipping Volume | 0.092 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Country of Origin | Australia |
| Price | AUD 3951 |
Documentation & Downloads
| Grundfos CRN 1S-19 A-CA-A-V-HQQV Product Data Sheet | Download PDF |
