Grundfos CRN 1S-10 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 96515940 (3 x 220-240D/380-415Y V)
by Grundfos
SKU 96515940
Original price
$2,227.50
-
Original price
$2,227.50
Original price
$2,227.50
$2,227.50
-
$2,227.50
Current price
$2,227.50
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, non-self-priming, multistage in-line centrifugal pump designed for installation in pipe systems or mounting on a foundation. Wetted components including the impellers, intermediate chambers, and outer sleeve are manufactured from high-grade stainless steel (EN 1.4401), while the pump head and base are stainless steel EN 1.4408. The pump features a single HQQV shaft seal according to EN 12756 and DIN/ANSI/JIS flanged pipe connections. Powered by a high-efficiency IE3 three-phase AC motor, the pump provides a rated flow of 0.9 m³/h with a rated head of 39.9 m and a maximum head of 58.9 m, making it suitable for demanding commercial, industrial, and water treatment applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1S-10 A-FGJ-A-V-HQQV |
| Product Number | 96515940 |
| EAN | 5700396734156 |
| Pump Type | Vertical / Multistage Centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 39.9 m |
| Maximum Head | 58.9 m |
| Speed (Pump Data) | 2873 rpm |
| Stages / Impellers | 10 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | Single, HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4 inch), DIN / ANSI / JIS, PN 25 / 300 lb |
| Base / Head Material | Stainless steel, EN 1.4408 / AISI 316 |
| Impeller Material | Stainless steel, EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.37 kW |
| Voltage | 3 x 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 1.74 / 1.00 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 73.8 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.54 |
| Net / Gross Weight | 23.5 / 26.3 kg |
| Shipping Volume | 0.063 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
