Grundfos CRN 1-27 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92901269 (1 x 220–230 V)
by Grundfos
SKU 92901269
Original price
$4,175.19
-
Original price
$4,175.19
Original price
$4,175.19
$4,175.19
-
$4,175.19
Current price
$4,175.19
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 1-27 A-CA-A-V-HQQV is a vertical inline multistage centrifugal pump designed for high-head water transfer, industrial water supply, pressure boosting, and solar water solutions. Wetted parts are made of high-grade stainless steel (EN 1.4401 / AISI 316), with a single HQQV cartridge shaft seal for reliability and easy maintenance. Power is transmitted via a rigid split coupling, and DN 32 FlexiClamp connections (PN 25) provide secure piping. The pump is equipped with a 1.5 kW, single-phase, fan-cooled IEC asynchronous motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Machining, wash, and clean systems
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply and wastewater handling
- Industrial process water treatment
- Desalination and reverse osmosis
- Surface water intake and drinking water treatment
- Water distribution and irrigation
- Solar water solutions and community water supply
- Rotor & spray irrigation, groundwater transfer, pivot irrigation
- Solar boosting, water supply, controls, and digital water management
- Fertigation, dosing, and agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1-27 A-CA-A-V-HQQV |
| Product Number | 92901269 |
| EAN | 5715121282260 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 117.8 m |
| Maximum Head | 163.2 m |
| Speed (Pump Data) | 2767 rpm |
| Stages / Impellers | 27 Stages / 27 Impellers |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | Single Mechanical Seal (HQQV) |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1 1/4 in) FlexiClamp, PN 25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 1.5 kW |
| Voltage | 1 x 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 8.75–9.1 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 81.3 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 39.8 kg / 42.7 kg |
| Shipping Volume | 0.13 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Price | AUD 6,073 |
Documentation & Downloads
| Grundfos CRN 1-27 Product Datasheet | Download PDF |
