Grundfos CRN 1-10 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 92901262 (1 x 220–230 V)
by Grundfos
SKU 92901262
Original price
$2,189.69
-
Original price
$2,189.69
Original price
$2,189.69
$2,189.69
-
$2,189.69
Current price
$2,189.69
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 1-10 A-CA-A-V-HQQV is a vertical inline multistage centrifugal pump designed for high-reliability water transfer, pressure boosting, and industrial liquid applications. All wetted parts are manufactured in high-grade stainless steel (EN 1.4401 / AISI 316) for excellent corrosion resistance. It features a single HQQV mechanical cartridge shaft seal for safe handling and easy maintenance. Power transmission is via a rigid split coupling, and the pump uses DN 32 FlexiClamp (PN 25) connections. It is powered by a 0.55 kW, single-phase, fan-cooled IEC asynchronous motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Machining, wash, and clean systems
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply and wastewater handling
- Industrial process water treatment
- Desalination and reverse osmosis
- Surface water intake and drinking water treatment
- Water distribution and irrigation
- Solar water solutions and community water supply
- Rotor & spray irrigation, groundwater transfer, pivot irrigation
- Solar boosting, water supply, controls, and digital water management
- Fertigation, dosing, and agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1-10 A-CA-A-V-HQQV |
| Product Number | 92901262 |
| EAN | 5715121282130 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 44.4 m |
| Maximum Head | 60.8 m |
| Speed (Pump Data) | 2750 rpm |
| Stages / Impellers | 10 Stages / 10 Impellers |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | Single Mechanical Seal (HQQV) |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1 1/4 in) FlexiClamp, PN 25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 0.55 kW |
| Voltage | 1 x 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 3.70–3.75 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 74.1 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 23.3 kg / 26.1 kg |
| Shipping Volume | 0.074 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRN 1-10 Product Datasheet | Download PDF |
