Grundfos CRI 1S-33 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96527594 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96527594
Original price
$2,401.44
-
Original price
$2,401.44
Original price
$2,401.44
$2,401.44
-
$2,401.44
Current price
$2,401.44
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, non-self-priming, multistage in-line centrifugal pump with suction and discharge ports on the same level. Pump materials in contact with the liquid are stainless steel (EN 1.4301 for impellers and intermediate chambers, EN 1.4408 for base and head). Shaft seal assembly according to EN 12756 (HQQE). Power transmission via cast iron split coupling. Pipework connections compatible with DIN / ANSI / JIS flanges. Driven by a 3-phase IEC 80C motor, 1.1 kW, 50 Hz, IE3 efficiency, IP55 enclosure.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRI 1S-33 A-FGJ-A-E-HQQE |
| Product Number | 96527594 |
| EAN | 5700397073179 |
| Pump Type | Vertical, Multistage Centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 128.7 m |
| Maximum Head | 192.3 m |
| Speed (Pump Data) | 2853 rpm |
| Stages / Impellers | 33 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE (Single) |
| Liquid Temperature Range | -20 .. 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4 inch), DIN / ANSI / JIS, PN 25 / 300 lb |
| Base / Head Material | Stainless Steel EN 1.4408 (AISI 316) |
| Impeller Material | Stainless Steel EN 1.4301 (AISI 304) |
| Bearing | SIC |
| Motor Power (P2) | 1.1 kW |
| Voltage | 3 x 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 4.35 / 2.50 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 82.7 % |
| Enclosure Class | IP55 Dust/Jetting |
| Insulation Class | F |
| MEI | 0.54 |
| Net / Gross Weight | 37.7 / 43 kg |
| Shipping Volume | 0.133 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| CRI 1S-33 A-FGJ-A-E-HQQE Product PDF | Download |
