Grundfos CRI 1S-33 A-CA-A-E-HQQE Vertical Multistage Centrifugal Pump – 92900152 (1 x 220-230V)
by Grundfos
SKU 92900152
Original price
$2,559.56
-
Original price
$2,559.56
Original price
$2,559.56
$2,559.56
-
$2,559.56
Current price
$2,559.56
📢 For orders over $100, FREE Shipping Australia-wide
Vertical inline multistage centrifugal pump constructed from stainless steel (EN 1.4301 / AISI 304) for high-pressure clean-water applications. The pump delivers 0.9 m³/h at 142.1 m head and features a cartridge HQQE shaft seal (SiC/SiC/EPDM) for reliable operation across a wide temperature range. The CA version uses FlexiClamp connections (DN32, PN25) and is driven by a 1-phase IEC fan-cooled asynchronous motor (1.1 kW, 220–230 V, 50 Hz) with IP55 enclosure, suitable for continuous industrial and commercial service.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling systems
- Process liquids transfer
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis systems
- Surface water intake and distribution
- Drinking water treatment
- Irrigation and agricultural water supply
- Community water supply
- Groundwater transfer
- Rotor, spray, and pivot irrigation
- Solar water solutions and boosting
- Fertigation, chemigation, and dosing
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRI 1S-33 A-CA-A-E-HQQE |
| Product Number | 92900152 |
| EAN | 5715121264402 |
| Pump Type | Vertical multistage centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 142.1 m |
| Maximum Head | 192 m |
| Speed (Pump Data) | 2789 rpm |
| Stages / Impellers | 33 / 33 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE (SiC/SiC/EPDM) |
| Liquid Temperature Range | −20 °C to +120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1¼ in) FlexiClamp, PN25 |
| Base / Head Material | Stainless steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless steel EN 1.4301 / AISI 304 |
| Bearing | Silicon carbide (SiC) |
| Motor Power (P2) | 1.1 kW |
| Voltage | 1 × 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 6.60–6.30 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 79.6 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.54 |
| Net / Gross Weight | 40.6 kg / 46 kg |
| Shipping Volume | 0.133 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet — CRI 1S-33 A-CA-A-E-HQQE (92900152) | Download |
