Grundfos CRI 1S-11 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96527559 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96527559
Original price
$1,355.06
-
Original price
$1,355.06
Original price
$1,355.06
$1,355.06
-
$1,355.06
Current price
$1,355.06
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1S-11 A-FGJ-A-E-HQQE is a vertical, non-self-priming, multistage in-line centrifugal pump designed for installation in pipe systems or mounting on a foundation. Featuring eleven stainless steel impellers (EN 1.4301) and a stainless steel pump head and base (EN 1.4408 / AISI 316), this model delivers a rated flow of 0.9 m³/h and a rated head of 43.5 m. The pump is equipped with a single HQQE shaft seal (EN 12756) and a high-efficiency 0.37 kW IE3 3-phase motor, suitable for commercial, industrial, and water treatment systems.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Process liquids transfer
- Machining
- Wash and clean systems
- Desalination
- Reverse osmosis – water treatment
- Drinking water treatment
- Water distribution
- Surface water intake
- Groundwater transfer
- Irrigation (pivot, rotor & spray)
- Community water supply
- Solar boosting and water supply solutions
- Solar water treatment, fertigation and dosing
- Agricultural solar solutions
- Livestock watering (solar solutions)
Key Specifications
| Product Name | CRI 1S-11 A-FGJ-A-E-HQQE |
| Product Number | 96527559 |
| EAN | 5700397072387 |
| Pump Speed (Data Based On) | 2873 rpm |
| Rated Flow | 0.9 m³/h |
| Rated Head | 43.5 m |
| Maximum Head | 64.5 m |
| Stages / Impellers | 11 / 11 |
| Pump Orientation | Vertical |
| Shaft Seal | Single, HQQE (EN 12756) |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Curve Tolerance | ISO 9906:2012 3B |
| Materials | |
| Base | Stainless Steel EN 1.4408 (AISI 316) |
| Impellers | Stainless Steel EN 1.4301 (AISI 304) |
| Bearing | SIC |
| Rubber Components | EPDM (Code E) |
| Installation | |
| Max Ambient Temperature | 60 °C |
| Max Operating Pressure | 25 bar |
| Max Pressure at Temp | 25 bar / 120 °C; 25 bar / -20 °C |
| Connection Type | DIN / ANSI / JIS (FGJ) |
| Inlet / Outlet | DN 25/32 (1 1/4 inch) |
| Pressure Rating | PN 25 |
| Flange Rating (Inlet) | 300 lb |
| Flange Size for Motor | FT85 |
| Terminal Box Position | 6 |
| Liquid | |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 .. 120 °C |
| Selected Liquid Temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Electrical Data | |
| Motor Type | IEC 71A |
| Rated Power (P2) | 0.37 kW |
| Mains Frequency | 50 Hz |
| Rated Voltage | 3 x 220-240D / 380-415Y V |
| Rated Current | 1.74 / 1.00 A |
| Rated Speed | 2850-2880 rpm |
| IE Efficiency Class | IE3 |
| Enclosure Class | IP55 |
| Insulation Class | F |
| Motor Protection | None |
| Other | |
| Minimum Efficiency Index (MEI) | ≥ 0.54 |
| Net Weight | 23.9 kg |
| Gross Weight | 26.8 kg |
| Shipping Volume | 0.074 m³ |
| Country of Origin | DK |
| Price | AUD 1971 |
Documentation & Downloads
| Data Sheet (PDF) | Download Product Data Sheet – CRI 1S-11 (96527559) |
