Grundfos CRI 1-9 A-CA-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901088 (1 x 220-230V)
by Grundfos
SKU 92901088
Original price
$1,265.00
-
Original price
$1,265.00
Original price
$1,265.00
$1,265.00
-
$1,265.00
Current price
$1,265.00
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-9 A-CA-A-E-HQQE is a vertical multistage inline centrifugal pump designed for reliable water transfer in commercial, industrial, and water treatment systems. The pump features stainless steel wetted components for corrosion resistance and durability. A cartridge mechanical shaft seal (HQQE) ensures safe operation and simplified maintenance. This model is equipped with a 0.55 kW single-phase IEC motor and FlexiClamp pipe connections for easy installation in compact piping systems.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean systems
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation systems
- Solar water solutions
- Community water supply
- Rotor and spray irrigation
- Groundwater transfer
- Pivot irrigation
- Solar boosting and water supply systems
- Solar controls and digital water management
- Solar fertigation and dosing systems
- Agricultural solar water solutions
- Livestock watering with solar systems
Key Specifications
| Flow rate | 1.8 m³/h |
| Rated head | 40.7 m |
| Maximum head | 55 m |
| Pump speed | 2750 rpm |
| Stages | 9 |
| Pump orientation | Vertical |
| Shaft seal | HQQE (Single mechanical cartridge seal) |
| Pumped liquid | Water |
| Liquid temperature range | -20 °C to 120 °C |
| Maximum operating pressure | 25 bar |
| Connection type | FlexiClamp |
| Inlet / Outlet connection | DN 32 (1 1/4 inch) |
| Pressure rating | PN 25 |
| Motor power (P2) | 0.55 kW |
| Power supply | 1 × 220-230 V, 50 Hz |
| Rated current | 3.70 – 3.75 A |
| Motor speed | 2800 – 2820 rpm |
| Efficiency class | IE2 |
| Enclosure class | IP55 |
| Insulation class | F |
| Impeller material | Stainless steel (EN 1.4301 / AISI 304) |
| Base material | Stainless steel (EN 1.4408 / AISI 316) |
| Bearing | SiC |
| Maximum ambient temperature | 40 °C |
| Minimum efficiency index (MEI) | ≥ 0.70 |
| Net weight | 23 kg |
| Gross weight | 25.7 kg |
| Country of origin | AU |
Documentation & Downloads
| Product Datasheet | Download PDF |
