Grundfos CRI 1-7 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901190 (1 x 220-230V)
by Grundfos
SKU 92901190
Original price
$1,259.50
-
Original price
$1,259.50
Original price
$1,259.50
$1,259.50
-
$1,259.50
Current price
$1,259.50
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-7 is a vertical multistage in-line centrifugal pump designed for demanding water transfer, pressure boosting, and industrial process applications. Wetted components are stainless steel (EN 1.4301) for corrosion resistance, with a stainless steel base (EN 1.4408 / AISI 316). It features a cartridge-type HQQE shaft seal for high reliability and easy service. The pump delivers a rated flow of 1.8 m³/h at a rated head of 31.6 m. Connections are combined DIN / ANSI / JIS flanges, and the pump is driven by a 0.37 kW single-phase IEC motor.
Suitable Applications
- Commercial heating systems
- Commercial air conditioning
- Commercial water pressure boosting
- Industrial water supply
- Industrial process water treatment
- Wash and cleaning systems
- Process liquid transfer
- Reverse osmosis and desalination systems
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation and agricultural water supply
Key Specifications
| Product Name | CRI 1-7 A-FGJ-A-E-HQQE |
| Product Number | 92901190 |
| EAN | 5715121280822 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 31.6 m |
| Maximum Head | 42.8 m |
| Speed (Pump Data) | 2757 rpm |
| Stages / Impellers | 7 Stages / 7 Impellers |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN25/32 (1 1/4") DIN / ANSI / JIS Flanged, PN25 / ANSI 300 lb |
| Base / Head Material | Stainless Steel EN 1.4408 (AISI 316) |
| Impeller Material | Stainless Steel EN 1.4301 (AISI 304) |
| Bearing | Silicon Carbide (SiC) |
| Motor Power (P2) | 0.37 kW |
| Voltage | 1 × 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 2.60–2.50 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 69.5 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 25.3 kg / 27.7 kg |
| Shipping Volume | 0.08 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
