Grundfos CRI 1-5 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901186 (1 x 220-230V)
by Grundfos
SKU 92901186
Original price
$1,194.19
-
Original price
$1,194.19
Original price
$1,194.19
$1,194.19
-
$1,194.19
Current price
$1,194.19
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-5 is a vertical multistage in-line centrifugal pump designed for reliable water transfer, pressure boosting, and industrial process applications. All wetted pump components are manufactured from stainless steel (EN 1.4301) for corrosion resistance, while the base is stainless steel EN 1.4408 (AISI 316). The pump is equipped with a cartridge-type HQQE shaft seal for dependable operation and simplified maintenance. With a rated flow of 1.8 m³/h and a rated head of 24 m, it is suitable for commercial, industrial, and water treatment systems. The pump features combined DIN / ANSI / JIS flanged connections and is powered by a 0.37 kW single-phase IEC motor.
Suitable Applications
- Commercial heating systems
- Commercial air conditioning
- Commercial water pressure boosting
- Industrial water supply
- Industrial process water treatment
- Wash and cleaning systems
- Process liquid transfer
- Reverse osmosis and desalination systems
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation and agricultural water supply
Key Specifications
| Product Name | CRI 1-5 A-FGJ-A-E-HQQE |
| Product Number | 92901186 |
| EAN | 5715121280754 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 24 m |
| Maximum Head | 31.2 m |
| Speed (Pump Data) | 2757 rpm |
| Stages / Impellers | 5 Stages / 5 Impellers |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN25/32 (1 1/4") DIN / ANSI / JIS Flanged, PN25 / ANSI 300 lb |
| Base / Head Material | Stainless Steel EN 1.4408 (AISI 316) |
| Impeller Material | Stainless Steel EN 1.4301 (AISI 304) |
| Bearing | Silicon Carbide (SiC) |
| Motor Power (P2) | 0.37 kW |
| Voltage | 1 × 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 2.60–2.50 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 69.5 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 24.5 kg / 26.9 kg |
| Shipping Volume | 0.08 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
