Grundfos CRI 1-33 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901212 (1 x 220-230V)
by Grundfos
SKU 92901212
Original price
$3,169.38
-
Original price
$3,169.38
Original price
$3,169.38
$3,169.38
-
$3,169.38
Current price
$3,169.38
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-33 is a vertical, in-line multistage centrifugal pump ideal for demanding industrial, commercial, and agricultural water applications. It features stainless steel construction for both the impellers (EN 1.4301) and base (EN 1.4408 / AISI 316), ensuring durability and corrosion resistance. Equipped with a reliable HQQE cartridge shaft seal, the pump provides safe handling, simple maintenance, and high operational reliability. Power is transmitted via a rigid split coupling, and the pump connects to piping through combined DIN / ANSI / JIS flanges. It is driven by a 2.2 kW IEC 90LD single-phase motor, delivering a rated head of 144.6 m at 1.8 m³/h.
Suitable Applications
- Commercial heating and air conditioning
- Water pressure boosting
- District heating & cooling
- Industrial water supply and wastewater
- Desalination and reverse osmosis
- Surface water intake and drinking water treatment
- Irrigation, rotor & spray, and pivot systems
- Solar water solutions and boosting
- Agricultural fertigation and dosing
- Livestock watering and community water supply
Key Specifications
| Product Name | CRI 1-33 A-FGJ-A-E-HQQE |
| Product Number | 92901212 |
| EAN | 5715121281058 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 144.6 m |
| Maximum Head | 199.8 m |
| Speed (Pump Data) | 2730 rpm |
| Stages / Impellers | 33 Stages / 33 Impellers |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN25/32 (1 1/4") DIN / ANSI / JIS Flanged, PN25 / ANSI 300 lb |
| Flange Size for Motor | FT115 |
| Base / Head Material | Stainless Steel EN 1.4408 (AISI 316) |
| Impeller Material | Stainless Steel EN 1.4301 (AISI 304) |
| Bearing | Silicon Carbide (SiC) |
| Motor Power (P2) | 2.2 kW |
| Voltage | 1 × 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 12.6–13.1 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 83.2 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 49.9 kg / 54.6 kg |
| Shipping Volume | 0.148 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
