Grundfos CRI 1-3 A-CA-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901081 (1 x 220-230V)
by Grundfos
SKU 92901081
Original price
$1,062.88
-
Original price
$1,062.88
Original price
$1,062.88
$1,062.88
-
$1,062.88
Current price
$1,062.88
📢 For orders over $100, FREE Shipping Australia-wide
Grundfos CRI 1-3 A-CA-A-E-HQQE is a vertical multistage centrifugal inline pump with suction and discharge ports on the same level, engineered for clean water transfer in commercial, industrial, and solar applications. All wetted components are manufactured from stainless steel (EN 1.4301 / AISI 304 and EN 1.4408 / AISI 316) to ensure corrosion resistance and durability. The pump delivers a rated flow of 1.8 m³/h and a rated head of 15.4 m (maximum head 19.1 m) at 2757 rpm. It features a cartridge-type single HQQE shaft seal, PN 25 DN 32 (1 1/4") FlexiClamp (CA) connections, and is driven by a 0.37 kW single-phase IEC motor (220–230 V, 50 Hz, IE2, IP55).
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and district cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis systems
- Drinking water treatment (WRAS, ACS approved)
- Water distribution and community water supply
- Irrigation (rotor, spray, pivot)
- Groundwater transfer and solar boosting
- Livestock watering and agricultural solar solutions
Key Specifications
| Product Name | CRI 1-3 A-CA-A-E-HQQE |
| Product Number | 92901081 |
| EAN | 5715121278959 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 15.4 m |
| Maximum Head | 19.1 m |
| Speed (Pump Data) | 2757 rpm |
| Stages / Impellers | 3 Stages / 3 Impellers |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | Single, HQQE (Cartridge) |
| Liquid Temperature Range | -20 °C to +120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1 1/4") Inlet/Outlet, FlexiClamp (CA), PN 25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4301 / AISI 304) |
| Bearing | Silicon Carbide (SIC) |
| Motor Power (P2) | 0.37 kW |
| Voltage | 1 × 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 2.60–2.50 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 69.5 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 19.5 kg / 22.2 kg |
| Shipping Volume | 0.054 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Data Booklet / Technical PDF | Download |
