Grundfos CRI 1-27 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96527712 (3 x 220-240D/380-415Y V)
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-27 A-FGJ-A-E-HQQE is a vertical, non-self-priming multistage centrifugal pump designed for high-pressure water transfer in industrial, commercial, and water treatment systems. The pump features stainless steel hydraulic components (EN 1.4301) with a stainless steel pump head and base (EN 1.4408 / AISI 316) for durability and corrosion resistance. It delivers a rated flow of 1.8 m³/h with a rated head of 128.3 m and a maximum head of 168 m. The pump uses a HQQE single mechanical shaft seal compliant with EN 12756 and is connected through DIN / ANSI / JIS flanges. Power transmission is via a cast iron split coupling and driven by an IE3 high-efficiency 3-phase IEC motor with IP55 enclosure protection.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Groundwater transfer
- Pivot irrigation
- Solar boosting and water supply systems
- Digital groundwater management systems
- Solar water treatment, fertigation and dosing
- Agricultural solar water systems
- Livestock watering systems
Key Specifications
| Product Name | CRI 1-27 A-FGJ-A-E-HQQE |
| Product Number | 96527712 |
| EAN | 5700397083765 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 128.3 m |
| Maximum Head | 168 m |
| Speed (Pump Data) | 2896 rpm |
| Stages / Impellers | 27 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE (Single Mechanical Seal) |
| Liquid Temperature Range | -20 .. 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4 inch), DIN / ANSI / JIS Flanges, PN25 / 300 lb |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4301 / AISI 304) |
| Bearing | SIC |
| Motor Power (P2) | 1.5 kW |
| Voltage | 3 x 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 5.70 / 3.30 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 84.2 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 41.6 kg / 44.5 kg |
| Shipping Volume | 0.13 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRI 1-27 A-FGJ-A-E-HQQE Product Data Sheet | Download |
