Grundfos CRI 1-25 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96527711 (3 x 220-240D/380-415Y V)
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-25 A-FGJ-A-E-HQQE is a vertical, non-self-priming multistage in-line centrifugal pump designed for installation in pipe systems or on a foundation. All liquid-contact components are stainless steel, with impellers, intermediate chambers, and outer sleeve manufactured from EN 1.4301 (AISI 304), while the pump head and base are made from EN 1.4408 (AISI 316). The pump is equipped with a HQQE single mechanical shaft seal according to EN 12756 and uses DIN / ANSI / JIS flange connections. Power transmission is via a cast iron split coupling and the unit is driven by a 1.5 kW IE3 three-phase AC motor, providing reliable performance for industrial, commercial, irrigation, and solar water applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment, fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRI 1-25 A-FGJ-A-E-HQQE |
| Product Number | 96527711 |
| EAN | 5700397083734 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 119.6 m |
| Maximum Head | 155.9 m |
| Speed (Pump Data) | 2896 rpm |
| Stages / Impellers | 25 / 25 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE (Single Mechanical Seal) |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4") DIN / ANSI / JIS, PN25, 300 lb |
| Base / Head Material | Stainless Steel EN 1.4408 (AISI 316) |
| Impeller Material | Stainless Steel EN 1.4301 (AISI 304) |
| Bearing | SIC |
| Motor Power (P2) | 1.5 kW |
| Voltage | 3 x 220-240D / 380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 5.70 / 3.30 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 84.2 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 40.7 / 43.6 kg |
| Shipping Volume | 0.13 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRI 1-25 Product Data Sheet | Download |
