Grundfos CRI 1-11 A-CA-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901090 (1 x 220-230V)
by Grundfos
SKU 92901090
Original price
$1,366.75
-
Original price
$1,366.75
Original price
$1,366.75
$1,366.75
-
$1,366.75
Current price
$1,366.75
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-11 A-CA-A-E-HQQE is a vertical multistage inline centrifugal pump designed for reliable water transfer in commercial, industrial, and water treatment systems. All wetted pump components are manufactured from stainless steel for excellent corrosion resistance and durability. The pump features a cartridge-type HQQE mechanical shaft seal for safe operation and simplified maintenance. It uses FlexiClamp pipe connections for quick installation and is driven by a 0.55 kW single-phase IEC fan-cooled asynchronous motor for efficient and dependable performance.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean systems
- Process liquids transfer
- Industrial heating
- Industrial cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor and spray irrigation
- Groundwater transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar fertigation and dosing systems
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRI 1-11 A-CA-A-E-HQQE |
| Product Number | 92901090 |
| EAN | 5715121279123 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 47.9 m |
| Maximum Head | 66.4 m |
| Speed (Pump Data) | 2750 rpm |
| Stages / Impellers | 11 / 11 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE |
| Liquid Temperature Range | -20 .. 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN32 (1 1/4") FlexiClamp, PN25 |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4301 / AISI 304) |
| Bearing | SiC |
| Motor Power (P2) | 0.55 kW |
| Voltage | 1 × 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 3.70 – 3.75 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 74.1 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 23.6 kg / 26.5 kg |
| Shipping Volume | 0.074 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
