Grundfos CRI 1-10 A-CA-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901089 (1 x 220-230V)
by Grundfos
SKU 92901089
Original price
$1,315.88
-
Original price
$1,315.88
Original price
$1,315.88
$1,315.88
-
$1,315.88
Current price
$1,315.88
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRI 1-10 A-CA-A-E-HQQE is a vertical multistage inline centrifugal pump designed for efficient water transfer in commercial, industrial, and water treatment applications. Constructed with stainless steel wetted components, the pump provides excellent corrosion resistance and long service life. It features a reliable HQQE cartridge mechanical shaft seal for easy maintenance and safe operation. The pump is equipped with a 0.55 kW single-phase IEC motor and FlexiClamp pipe connections for fast installation and secure piping integration.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean systems
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation systems
- Solar water solutions
- Community water supply
- Rotor and spray irrigation
- Groundwater transfer
- Pivot irrigation
- Solar boosting and water supply systems
- Solar controls and digital water management
- Solar fertigation and dosing systems
- Agricultural solar water solutions
- Livestock watering with solar systems
Key Specifications
| Flow rate | 1.8 m³/h |
| Rated head | 44.4 m |
| Maximum head | 60.8 m |
| Pump speed | 2750 rpm |
| Stages | 10 |
| Pump orientation | Vertical |
| Shaft seal | HQQE (Single mechanical cartridge seal) |
| Pumped liquid | Water |
| Liquid temperature range | -20 °C to 120 °C |
| Maximum operating pressure | 25 bar |
| Connection type | FlexiClamp |
| Inlet / Outlet connection | DN 32 (1 1/4 inch) |
| Pressure rating | PN 25 |
| Motor power (P2) | 0.55 kW |
| Power supply | 1 × 220-230 V, 50 Hz |
| Rated current | 3.70 – 3.75 A |
| Motor speed | 2800 – 2820 rpm |
| Efficiency class | IE2 |
| Enclosure class | IP55 |
| Insulation class | F |
| Impeller material | Stainless steel (EN 1.4301 / AISI 304) |
| Base material | Stainless steel (EN 1.4408 / AISI 316) |
| Bearing | SiC |
| Maximum ambient temperature | 40 °C |
| Minimum efficiency index (MEI) | ≥ 0.70 |
| Net weight | 23.4 kg |
| Gross weight | 26.2 kg |
| Country of origin | AU |
Documentation & Downloads
| Product Datasheet | Download PDF |
