Grundfos CR 95-2 A-F-A-E-HQQE Vertical Multistage Centrifugal Pump – 99141738 (3 x 380-415D/660-690YV)
by Grundfos
SKU 99141738
Original price
$9,072.25
-
Original price
$9,072.25
Original price
$9,072.25
$9,072.25
-
$9,072.25
Current price
$9,072.25
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal inline pump (CR 95-2 A-F-A-E-HQQE) with suction and discharge ports on the same level, designed for high-head water transfer and pressure boosting. The pump head and base are ductile cast iron, while all wetted parts are stainless steel (EN 1.4301 / AISI 304) for durability and corrosion resistance. It delivers a rated flow of 95 m³/h with a rated head of 45.7 m (maximum 62.5 m) at 2956 rpm. The HQQE single cartridge shaft seal ensures reliable, low-maintenance operation. Pipe connections are DN 100 DIN PN16 flanges, and the pump is powered by a 15 kW, 3-phase IEC IE3 fan-cooled asynchronous motor (380–415 V Δ / 660–690 V Y, 50 Hz, IP55, Class F).
Suitable Applications
- Commercial heating and air conditioning systems
- Commercial water pressure boosting
- District heating and cooling
- Industrial water supply and wastewater handling
- Industrial process water transfer and treatment
- Desalination and reverse osmosis systems
- Drinking water treatment and distribution
- Surface water intake and groundwater transfer
- Irrigation, agriculture, and pivot systems
- Solar water supply and boosting solutions
- Community water supply
- Rotor and spray irrigation
- Machining wash and clean processes
- Livestock watering with solar solutions
Key Specifications
| Product Name | CR 95-2 A-F-A-E-HQQE |
| Product Number | 99141738 |
| EAN | 5712607527198 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 95 m³/h |
| Rated Head | 45.7 m |
| Maximum Head | 62.5 m |
| Speed (Pump Data) | 2956 rpm |
| Stages / Impellers | 2 / 2 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE (Single cartridge) |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 16 bar |
| Connections | DN 100 / DN 100, DIN PN16 flanges |
| Base / Head Material | Ductile cast iron (EN-GJS-500-7) |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Bearing | WC/WC with Graflon support bearing |
| Motor Power (P2) | 15 kW |
| Voltage | 3 × 380–415 V (Δ) / 660–690 V (Y) |
| Frequency | 50 Hz |
| Rated Current | 28.0–26.0 A / 16.2–15.6 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 91.9 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 199 / 242 kg |
| Shipping Volume | 0.611 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, ACS |
Documentation & Downloads
| Product Data Sheet – CR 95-2 A-F-A-E-HQQE | Download |
