Grundfos CR 5-4 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92902360 (1 x 220-230V)
by Grundfos
SKU 92902360
Original price
$1,221.00
-
Original price
$1,221.00
Original price
$1,221.00
$1,221.00
-
$1,221.00
Current price
$1,221.00
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 5-4 A-A-A-E-HQQE is a vertical, multistage centrifugal inline pump designed for demanding commercial, industrial, and water treatment applications. The pump head and base are manufactured from cast iron, while all other wetted parts are made from stainless steel (EN 1.4301). It features a cartridge shaft seal for high reliability, easy servicing, and safe handling, and is fitted with a single-phase, fan-cooled asynchronous motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and district cooling
- Industrial heating and cooling systems
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis water treatment
- Drinking water treatment and water distribution
- Surface and groundwater transfer
- Irrigation and agricultural water supply
- Solar water boosting and solar water supply solutions
- Livestock watering and community water supply
Key Specifications
| Product Number | 92902360 |
| Pump Type | Vertical multistage centrifugal (inline) |
| Rated Flow | 5.8 m³/h |
| Rated Head | 17.4 m |
| Maximum Head | 26.3 m |
| Number of Stages | 4 |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 16 bar |
| Shaft Seal | HQQE (Single) |
| Base Material | Cast iron (EN-GJL-200) |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Motor Power (P2) | 0.55 kW |
| Rated Voltage | 1 × 220–230 V, 50 Hz |
| Motor Efficiency Class | IE2 |
| Connection Size | 1 1/4 inch inlet / outlet |
| Connection Pressure Rating | PN 16 |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Net Weight | 22.8 kg |
| Country of Origin | AU |
Documentation & Downloads
| Product Data Sheet (PDF) | Download |
