Grundfos CR 5-2 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92902347 (1 x 220-230V)
by Grundfos
SKU 92902347
Original price
$1,065.63
-
Original price
$1,065.63
Original price
$1,065.63
$1,065.63
-
$1,065.63
Current price
$1,065.63
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 5-2 A-A-A-E-HQQE is a vertical, multistage centrifugal pump with suction and discharge ports on the same level (inline). The pump head and base are made of cast iron, while all other wetted parts are stainless steel (EN 1.4301). It features a cartridge shaft seal for high reliability, safe handling, and easy maintenance. Power is transmitted via a rigid split coupling, and the pump is fitted with a 1-phase, fan-cooled asynchronous motor.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Model | CR 5-2 A-A-A-E-HQQE |
| Product Number | 92902347 |
| EAN | 5715121299152 |
| Pump Speed (Data Based) | 2757 rpm |
| Rated Flow | 5.8 m³/h |
| Rated Head | 7.9 m |
| Maximum Head | 13.2 m |
| Stages | 2 |
| Impellers | 2 |
| Pump Orientation | Vertical |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQE |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 °C to 120 °C |
| Selected Liquid Temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Maximum Operating Pressure | 16 bar |
| Connections | Oval / Rp, 1 1/4 inch, PN 16 |
| Materials |
Pump head & base: Cast iron (EN 1561 EN-GJL-200, ASTM A48-25B) Impeller & wetted parts: Stainless steel (EN 1.4301 / AISI 304) Bearing: SIC |
| Motor Standard | IEC |
| Motor Type | 71C |
| Motor Power (P2) | 0.37 kW |
| Rated Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| IE Efficiency Class | IE2 |
| Rated Speed | 2700-2730 rpm |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Curve Tolerance | ISO 9906:2012 3B |
| Minimum Efficiency Index (MEI) | ≥ 0.57 |
| Net Weight | 21.2 kg |
| Gross Weight | 23.9 kg |
| Country of Origin | AU |
Documentation & Downloads
| Product Datasheet – CR 5-2 A-A-A-E-HQQE | Download PDF |
