Grundfos CR 5-16 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92902373 (1 x 220-230V))
by Grundfos
SKU 92902373
Original price
$2,379.44
-
Original price
$2,379.44
Original price
$2,379.44
$2,379.44
-
$2,379.44
Current price
$2,379.44
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 5-16 A-A-A-E-HQQE is a vertical, multistage centrifugal inline pump suitable for industrial, commercial, and water treatment applications. The pump head and base are cast iron, while all other wetted parts are stainless steel (EN 1.4301). A cartridge shaft seal ensures high reliability, safe handling, and easy access for service. Power transmission is via a rigid split coupling. The pump is fitted with a 1-phase, fan-cooled asynchronous motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and district cooling
- Industrial heating and cooling
- Industrial water supply and wastewater management
- Industrial process water treatment
- Desalination and reverse osmosis water treatment
- Drinking water treatment and water distribution
- Surface water intake and groundwater transfer
- Irrigation, rotor & spray irrigation, pivot systems
- Solar boosting, solar water solutions, and community water supply
- Agriculture solar solutions and fertigation/dosing
- Livestock watering with solar solutions
Key Specifications
| Product Number | 92902373 |
| Pump Type | Vertical multistage centrifugal (inline) |
| Rated Flow | 5.8 m³/h |
| Rated Head | 71.4 m |
| Maximum Head | 105.2 m |
| Stages / Impellers | 16 / 16 |
| Pump Speed (Data Basis) | 2730 rpm |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 16 bar |
| Shaft Seal | HQQE (Single) |
| Base Material | Cast iron (EN-GJL-200) |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Motor Power (P2) | 2.2 kW |
| Rated Voltage | 1 × 220–230 V, 50 Hz |
| Motor Efficiency Class | IE2 |
| Connection Size | 1 1/4 inch inlet / outlet |
| Connection Pressure Rating | PN 16 |
| Flange Size | FT115 |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Net Weight | 43.3 kg |
| Gross Weight | 46.2 kg |
| Shipping Volume | 0.13 m³ |
| Country of Origin | AU |
| EAN Number | 5715121299565 |
| Price | AUD 3461 |
Documentation & Downloads
| Product Data Sheet (PDF) | Download |
