Grundfos CR 45-9 A-F-A-E-HQQE Vertical Multistage Centrifugal Pump – 96122813 (3 x 380-420D/660-725Y)
by Grundfos
SKU 96122813
Original price
$15,627.56
-
Original price
$15,627.56
Original price
$15,627.56
$15,627.56
-
$15,627.56
Current price
$15,627.56
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, non-self-priming, multistage in-line centrifugal pump with cast iron head and base, and stainless steel (EN 1.4301 / AISI 304) wetted parts. Equipped with a single HQQE shaft seal, DN 80 DIN PN40 flanged connections, and a 37 kW IE3 3-phase motor. Rated flow of 45 m³/h with a maximum head of 230.2 m, suitable for industrial, commercial, water treatment, and solar water applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination and reverse osmosis
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Community water supply
- Groundwater transfer
- Livestock watering
Key Specifications
| Product Name | CR 45-9 A-F-A-E-HQQE |
| Product Number | 96122813 |
| EAN | 5700396688572 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 45 m³/h |
| Rated Head | 185 m |
| Maximum Head | 230.2 m |
| Speed (Pump Data) | 2957 rpm |
| Stages / Impellers | 9 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE (Single) |
| Liquid Temperature Range | -30 .. 120 °C |
| Maximum Operating Pressure | 30 bar |
| Connections | DN 80 / DN 80, DIN PN40 |
| Base / Head Material | Cast iron |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Bearing | SIC / Graflon Support Bearing |
| Motor Power (P2) | 37 kW |
| Voltage | 3 × 380–420D / 660–725Y V |
| Frequency | 50 Hz |
| Rated Current | 65 / 37.5 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 93.7 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 357 / 402 kg |
| Shipping Volume | 0.808 m³ |
| Approvals | CE, EAC, UKCA, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
