Grundfos CR 3-6 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516653 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516653
Original price
$1,123.38
-
Original price
$1,123.38
Original price
$1,123.38
$1,123.38
-
$1,123.38
Current price
$1,123.38
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-6 A-FGJ-A-E-HQQE is a vertical, non-self-priming, multistage
inline centrifugal pump designed for installation in pipe systems and on a
foundation. The pump features a cast iron head and base, with all wetted parts
made from stainless steel (EN 1.4301 / AISI 304).
It includes a
single HQQE shaft seal, cast iron split coupling for power transmission, and
DIN / ANSI / JIS flange connections. Powered by a 3-phase IEC motor (71B) with
IE3 efficiency, it is ideal for commercial, industrial, agricultural, and
solar water applications.
Key Features & Benefits
- Vertical multistage centrifugal inline pump
- Cast iron pump head and base with stainless steel impellers
- Single HQQE cartridge shaft seal for reliable performance
- DIN / ANSI / JIS flange connections
- Approved for drinking water (WRAS & ACS)
- Wide liquid temperature range: -20°C to 120°C
- 3-phase IEC motor (71B) with IE3 efficiency
- Suitable for commercial, industrial, agricultural, and solar applications
Key Specifications
| Product Code | CR 3-6 A-FGJ-A-E-HQQE |
| Product Number | 96516653 |
| Rated Flow | 3 m³/h |
| Rated Head | 28.5 m |
| Maximum Head | 39.5 m |
| Stages / Impellers | 6 / 6 |
| Motor Power (P2) | 0.55 kW |
| Voltage / Frequency | 3 × 220-240D / 380-415Y V, 50 Hz |
| Max Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Size | DN 25/32 (1 1/4") |
| Shaft Seal | HQQE (Single) |
| Net Weight | 23.8 kg |
| Gross Weight | 26.6 kg |
| Country of Origin | TW |
Documentation & Downloads
| Document | Download |
|---|---|
| Product Datasheet / Technical PDF | 📄 Download PDF |
