Grundfos CR 3-3 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516591 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516591
Original price
$931.56
-
Original price
$931.56
Original price
$931.56
$931.56
-
$931.56
Current price
$931.56
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-3 A-A-A-E-HQQE is a vertical, non-self-priming, multistage, in-line centrifugal pump designed for installation in pipe systems and mounting on a foundation. It features stainless steel impellers and intermediate chambers (EN 1.4301), a robust cast iron pump head and base, and an HQQE shaft seal manufactured to EN 12756 standards. Power is transmitted via a cast iron split coupling, and the pump is driven by a high-efficiency IE3 3-phase AC motor, making it suitable for demanding commercial, industrial, and water treatment applications.
Applications & Suitable Uses:
- Commercial heating and air conditioning systems
- Commercial water pressure boosting
- District heating and district cooling
- Industrial water supply and wastewater treatment
- Process liquids transfer, machining, and wash & clean systems
- Desalination and reverse osmosis water treatment
- Surface water intake and drinking water treatment
- Water distribution and irrigation systems
- Rotor, spray, and pivot irrigation
- Solar boosting and solar water supply solutions
- Agriculture and livestock watering with solar solutions
Key Specifications:
| SKU | 96516591 |
| Rated Flow | 3 m³/h |
| Rated Head | 15.1 m |
| Maximum Head | 19.9 m |
| Number of Stages | 3 |
| Pump Orientation | Vertical |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Motor Power (P2) | 0.37 kW |
| Rated Voltage | 3 × 220–240D / 380–415Y V |
| Efficiency Class | IE3 |
| Net Weight | 18.5 kg |
Documentation & Downloads:
| Document | Download |
|---|---|
| Grundfos CR 3-3 Product Datasheet | 📄 Download PDF |
