Grundfos CR 3-21 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516664 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516664
Original price
$2,028.13
-
Original price
$2,028.13
Original price
$2,028.13
$2,028.13
-
$2,028.13
Current price
$2,028.13
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-21 A-FGJ-A-E-HQQE is a vertical, non-self-priming,
multistage inline centrifugal pump designed for installation in pipe systems
or mounting on a foundation. The pump head and base are manufactured from
durable cast iron, while all other wetted components are made from stainless
steel (EN 1.4301 / AISI 304).
This model features a single HQQE shaft seal in accordance with EN 12756, cast
iron split coupling, and DIN / ANSI / JIS flanged connections. Powered by a
high-efficiency IE3 3-phase IEC motor, the CR 3-21 is ideal for high-pressure
commercial, industrial, agricultural, and solar water applications.
Key Features & Benefits
- Vertical multistage inline centrifugal pump
- Cast iron pump head and base
- Stainless steel impellers and chambers (EN 1.4301 / AISI 304)
- Single HQQE shaft seal to EN 12756
- DIN / ANSI / JIS flanged connections
- Approved for drinking water applications (WRAS & ACS)
- Wide liquid temperature range from -20°C to 120°C
- High-efficiency IE3 3-phase IEC motor
Key Specifications
| Product Code | CR 3-21 A-FGJ-A-E-HQQE |
| Product Number | 96516664 |
| Rated Flow | 3 m³/h |
| Rated Head | 103.6 m |
| Maximum Head | 139.9 m |
| Stages / Impellers | 21 / 21 |
| Motor Power (P2) | 2.2 kW |
| Voltage / Frequency | 3 × 220–240D / 380–415Y V, 50 Hz |
| Maximum Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Size | DN 25/32 (1 1/4") |
| Shaft Seal | HQQE (Single) |
| Net Weight | 45.2 kg |
| Country of Origin | TW |
Documentation & Downloads
| Document | Download |
|---|---|
| Product Datasheet / Technical PDF | 📄 Download PDF |
