Grundfos CR 3-2 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516649 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516649
Original price
$943.94
-
Original price
$943.94
Original price
$943.94
$943.94
-
$943.94
Current price
$943.94
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-2 A-FGJ-A-E-HQQE is a vertical, non-self-priming, multistage
inline centrifugal pump designed for installation in pipe systems and on a
foundation. The pump head and base are made of cast iron, while impellers and
intermediate chambers are stainless steel (EN 1.4301 / AISI 304).
It features a single HQQE shaft seal for high reliability and easy
maintenance. Power transmission is via a cast iron split coupling. Pipe
connections are compatible with DIN / ANSI / JIS standards. Driven by a
3-phase IEC motor, this pump is ideal for commercial, industrial,
agricultural, and solar water applications.
Key Features & Benefits
- Vertical multistage centrifugal inline pump
- Cast iron pump head and base with stainless steel impellers
- Reliable HQQE cartridge shaft seal
- DIN / ANSI / JIS flange connections
- Approved for drinking water (WRAS & ACS)
- Wide liquid temperature range: -20°C to 120°C
- 3-phase IEC motor with IE3 efficiency
- Suitable for commercial, industrial, agricultural, and solar applications
Key Specifications
| Product Code | CR 3-2 A-FGJ-A-E-HQQE |
| Product Number | 96516649 |
| Rated Flow | 3 m³/h |
| Rated Head | 9.6 m |
| Maximum Head | 13.5 m |
| Stages / Impellers | 3 / 2 |
| Motor Power (P2) | 0.37 kW |
| Voltage / Frequency | 3 × 220-240D / 380-415Y V, 50 Hz |
| Max Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Size | DN 25/32 (1 1/4") |
| Shaft Seal | HQQE (Single) |
| Net Weight | 22.9 kg |
| Gross Weight | 25.5 kg |
| Country of Origin | TW |
Documentation & Downloads
| Document | Download |
|---|---|
| Product Datasheet / Technical PDF | 📄 Download PDF |
