The Grundfos CR 3-19 A-FGJ-A-E-HQQE is a vertical, non-self-priming,
multistage inline centrifugal pump designed for installation in pipe systems
or mounting on a foundation. The pump features a cast iron head and base, with
all other wetted components manufactured from stainless steel (EN 1.4301 /
AISI 304).
It is equipped with a single HQQE shaft seal, cast iron split coupling, and
DIN / ANSI / JIS flange connections. Driven by a high-efficiency IE3 3-phase
IEC motor, this pump is suitable for demanding commercial, industrial,
agricultural, and solar water applications.
Key Features & Benefits
- Vertical multistage inline centrifugal pump
- Cast iron pump head and base
- Stainless steel impellers and chambers (EN 1.4301 / AISI 304)
- Single HQQE shaft seal to EN 12756
- DIN / ANSI / JIS flanged connections
- Approved for drinking water applications (WRAS & ACS)
- Wide liquid temperature range from -20°C to 120°C
- IE3 high-efficiency 3-phase IEC motor
Key Specifications
| Product Code | CR 3-19 A-FGJ-A-E-HQQE |
| Product Number | 96516663 |
| Rated Flow | 3 m³/h |
| Rated Head | 92.5 m |
| Maximum Head | 125.8 m |
| Stages / Impellers | 19 / 19 |
| Motor Power (P2) | 1.5 kW |
| Voltage / Frequency | 3 × 220–240D / 380–415Y V, 50 Hz |
| Maximum Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Size | DN 25/32 (1 1/4") |
| Shaft Seal | HQQE (Single) |
| Net Weight | 40.6 kg |
| Country of Origin | TW |
